4.5. Outdoor units: CU-2E15CBPG / CU-2E18CBPG
Outdoor Unit Indoor unit combination Operation
mode
Capacity (kW) Power input (kW) Current (A)
Operation Class (kW) Rating mini - max Rating mini - max
CU-2E15CBPG One-room
Operation
2.2 Cooling 2.20 1.1 - 2.9 0.52 0.22 - 0.75 2.45
Heating 3.20 0.7 - 4.8 0.85 0.17 - 1.41 3.75
2.8 Cooling 2.80 1.1 - 3.5 0.75 0.22 - 1.00 3.50
Heating 4.00 0.7 - 5.5 1.15 0.17 -1.70 5.10
Two-room
Operation
2.2 + 2.2 Cooling 4.50 1.5 - 5.0 1.23 0.25 - 1.35 5.75
Heating 5.40 1.1 - 7.0 1.17 0.21 - 1.67 5.20
2.2 + 2.8* Cooling 4.50 1.5 - 5.2 1.23 0.25 - 1.52 5.75
Heating 5.40 1.1 - 7.0 1.17 0.21 - 1.67 5.20
CU-2E18CBPG One-room
Operation
2.2 Cooling 2.20 1.1 - 2.9 0.52 0.22 - 0.75 2.45
Heating 3.20 0.7 - 4.8 0.85 0.17 - 1.41 3.75
2.8 Cooling 2.80 1.1 - 3.5 0.75 0.22 - 1.00 3.50
Heating 4.00 0.7 - 5.5 1.15 0.17 -1.70 5.10
3.2 Cooling 3.20 1.1 - 4.0 0.92 0.22 - 1.22 4.30
Heating 4.50 0.7 - 6.2 1.25 0.17 - 1.81 5.55
Two-room
Operation
2.2 + 2.2 Cooling 4.50 1.5 - 5.0 1.23 0.25 - 1.35 5.75
Heating 5.40 1.1 - 7.0 1.17 0.21 - 1.67 5.20
2.2 + 2.8* Cooling 4.50 1.5 - 5.2 1.23 0.25 - 1.52 5.75
Heating 5.40 1.1 - 7.0 1.17 0.21 - 1.67 5.20
2.2 + 3.2 Cooling 4.80 1.5 - 5.3 1.31 0.25 - 1.54 6.10
Heating 5.60 1.1 - 7.2 1.23 0.21 - 1.72 5.45
2.8* + 2.8* Cooling 4.80 1.5 - 5.2 1.31 0.25 - 1.52 6.10
Heating 5.60 1.1 - 7.2 1.25 0.21 - 1.74 5.55
2.8* + 3.2 Cooling 5.00 1.5 - 5.3 1.49 0.25 - 1.54 6.95
Heating 5.60 1.1 - 7.2 1.23 0.21 - 1.72 5.45
3.2 + 3.2 Cooling 5.20 1.5 - 5.4 1.52 0.25 - 1.58 7.10
Heating 5.60 1.1 - 7.2 1.21 0.21 - 1.70 5.35
Note:
1. "2.8 kW" Class model indicates CS-ME10DD3EG (Duct) and CS-ME10DTEG (Ceiling Floor)."
2. A combination of "2.8 kW + 2.8 kW" includes the following:
•
• •
•
"CS-ME10DD3EG (Duct)" + "CS-ME10DD3EG (Duct)"
•
• •
•
"CS-ME10DD3EG (Duct)" + "CS-E9DKEW (Wall)"
•
• •
•
"CS-ME10DD3EG (Duct)" + "CS-E9DKRW (Wall)"
•
• •
•
"CS-ME10DDTEG (Ceiling Floor)" + "CS-ME10DTEG (Ceiling Floor)"
•
• •
•
"CS-ME10DTEG (Ceiling Floor)" + "CS-E9DKEW (Wall)"
•
• •
•
"CS-ME10DTEG (Ceiling Floor)" + "CS-E9DKRW (Wall)"
•
• •
•
"CS-ME10DTEG (Ceiling Floor)" + "CS-ME10DD3EG (Duct)"
