4.6. Outdoor units: CU-3E23CBPG / CU-4E27CBPG
Outdoor Unit Indoor unit combination Operation
mode
Capacity (kW) Power input (kW) Current (A)
Operation Class (kW) Rating mini - max Rating mini - max
CU-3E23CBPG One-room
Operation
2.2 Cooling 2.20 1.9 - 2.7 0.45 0.38 - 0.62 2.25
Heating 3.20 1.7 - 4.1 0.84 0.37 - 1.31 3.85
2.8 Cooling 2.80 2.0 - 3.4 0.62 0.38 - 0.90 2.95
Heating 4.00 1.7 - 4.3 1.21 0.37 - 1.40 5.40
3.2 Cooling 3.20 2.0 - 3.9 0.72 0.38 - 1.09 3.40
Heating 4.50 1.7 - 5.7 1.31 0.37 - 1.91 5.85
4.0 Cooling 4.00 2.0 - 4.4 1.03 0.38 - 1.39 4.60
Heating 5.60 1.8 - 7.2 1.90 0.37 - 2.92 8.35
5.0 Cooling 5.00 2.1 - 5.2 1.61 0.40 - 1.80 7.15
Heating 7.10 2.1 - 7.3 2.84 0.43 - 2.89 12.40
Two-room
Operation
2.2 + 2.2 Cooling 4.40 2.1 - 5.0 0.98 0.40 - 1.26 4.45
Heating 6.30 1.8 - 8.6 1.41 0.40 - 2.57 6.25
2.2 + 2.8 Cooling 5.00 2.1 - 6.1 1.23 0.40 - 1.88 5.50
Heating 7.10 2.1 - 8.6 1.70 0.42 - 2.57 7.55
2.2 + 3.2 Cooling 5.40 2.2 - 7.0 1.37 0.40 - 2.79 6.10
Heating 7.50 2.2 - 8.7 1.74 0.42 - 2.97 7.75
2.2 + 4.0 Cooling 6.20 2.2 - 7.1 1.82 0.40 - 2.79 8.00
Heating 8.20 2.4 - 8.7 2.01 0.44 - 2.97 8.85
2.2 + 5.0 Cooling 6.80 2.5 - 7.1 2.24 0.46 - 2.80 9.85
Heating 8.60 3.2 - 9.0 2.16 0.53 - 2.96 9.50
2.8 + 2.8 Cooling 5.60 2.2 - 6.9 1.55 0.40 - 2.78 6.85
Heating 7.70 2.3 - 8.7 1.93 0.44 - 3.04 8.45
2.8 + 3.2 Cooling 6.00 2.2 - 7.0 1.70 0.40 - 2.79 7.55
Heating 8.00 2.4 - 8.8 1.97 0.44 - 3.02 8.60
2.8 + 4.0 Cooling 6.80 2.2 - 7.1 2.39 0.46 - 2.79 10.50
Heating 8.60 2.1 - 9.0 2.175 0.53 - 3.03 9.55
2.8 + 5.0 Cooling 6.80 2.5 - 7.2 2.23 0.46 - 2.80 9.85
Heating 8.60 3.2 - 9.0 2.15 0.53 - 3.01 9.50
3.2 + 3.2 Cooling 6.40 2.2 - 7.3 1.86 0.40 - 2.81 8.15
Heating 8.40 2.5 - 9.0 2.05 0.47 - 2.97 9.05
3.2 + 4.0 Cooling 6.80 2.5 - 7.3 2.22 0.46 - 2.81 9.65
Heating 8.60 3.2 - 9.0 2.09 0.53 - 2.97 9.20
3.2 + 5.0 Cooling 6.80 2.6 - 7.4 2.12 0.46 - 2.82 9.30
Heating 8.60 3.2 - 9.0 2.08 0.53 - 2.95 9.15
4.0 + 4.0 Cooling 6.80 2.5 - 7.3 2.19 0.46 - 2.81 9.65
Heating 8.60 3.2 - 9.0 2.08 0.53 - 2.97 9.15
4.0 + 5.0 Cooling 6.80 2.7 - 7.4 2.11 0.48 - 2.82 9.30
Heating 8.60 3.2 - 9.1 2.07 053 - 2.95 9.15
5.0 + 5.0 Cooling 6.80 2.8 - 7.4 2.07 0.48 - 2.82 9.15
Heating 8.60 3.5 - 9.1 2.07 0.59 - 2.94 9.15
Three-room
Operation
2.2 + 2.2 +
2.2
Cooling 6.60 2.2 - 7.7 1.85 0.41 - 2.45 8.10
Heating 8.53 3.1 - 8.9 1.94 0.50 - 2.80 8.50
2.2 + 2.2 +
2.8
Cooling 6.80 2.5 - 8.1 1.98 0.46 - 2.82 8.70
Heating 8.60 3.2 - 8.9 1.98 0.51 - 2.80 8.70
2.2 + 2.2 +
3.2
Cooling 6.80 2.5 - 8.1 1.99 0.46 - 2.79 8.80
Heating 8.60 3.2 - 9.0 1.96 0.51 - 2.78 8.60
2.2 + 2.2 +
4.0
Cooling 6.80 2.6 - 8.2 1.97 0.46 - 2.79 8.60
Heating 8.60 3.2 - 8.8 1.94 0.51 - 2.76 8.50
2.2 + 2.2 +
5.0
Cooling 6.80 2.8 - 8.3 1.96 0.49 - 2.79 8.60
Heating 8.60 3.2 - 8.8 1.92 0.51 - 2.76 8.45
2.2 + 2.8 +
2.8
Cooling 6.80 2.5 - 8.1 1.95 0.46 - 2.78 8.50
Heating 8.60 3.2 - 9.0 1.93 0.51 - 2.73 8.45
2.2 + 2.8 +
3.2
Cooling 6.80 2.6 - 8.1 1.98 0.46 - 2.79 8.70
Heating 8.60 3.2 - 8.8 1.93 0.51 - 2.76 8.45
2.2 + 2.8 +
4.0
Cooling 6.80 2.7 - 8.2 1.96 0.49 - 2.79 8.60
Heating 8.60 3.2 - 9.0 1.91 0.51 - 2.76 8.35
2.2 + 2.8 +
5.0
Cooling 6.80 2.8 - 8.3 1.95 0.49 - 2.79 8.50
Heating 8.60 3.5 - 9.0 1.92 0.56 - 2.73 8.45
2.2 + 3.2 +
3.2
Cooling 6.80 2.7 - 8.3 1.97 0.46 - 2.80 8.60
Heating 8.60 3.2 - 9.1 1.91 0.50 - 2.71 8.35
2.2 + 3.2 +
4.0
Cooling 6.80 2.8 - 8.3 1.95 0.49 -2.80 8.50
Heating 8.60 3.2 - 9.0 1.89 0.50 - 2.71 8.25
2.8 + 2.8 +
2.8
Cooling 6.78 2.6 - 8.1 1.94 0.46 - 2.82 8.50
Heating 8.58 3.2 - 9.0 1.91 0.51 - 2.76 8.35
