Panasonic CS-E18DB4EW Service Manual

Outdoor Unit Indoor unit combination Operation
mode
Capacity (kW) Power input (kW) Current (A)
Operation Class (kW) Rating mini - max Rating mini - max
CU-3E23CBPG Three-room
Operation
2.8 + 2.8 +
3.2
Cooling 6.80 2.7 - 8.2 1.96 0.49 - 2.79 8.60
Heating 8.60 3.2 - 9.0 1.92 0.51 - 2.76 8.45
2.8 + 2.8 +
4.0
Cooling 6.80 2.8 - 8.2 1.95 0.49 - 2.79 8.50
Heating 8.60 3.3 - 9.0 1.90 0.53 - 2.76 8.35
2.8 + 3.2 +
3.2
Cooling 6.80 2.7 - 8.3 1.96 0.49 - 2.80 8.60
Heating 8.60 3.2 - 9.0 1.90 0.50 - 2.71 8.35
2.8 + 3.2 +
4.0
Cooling 6.80 2.8 - 8.4 1.95 0.49 - 2.80 8.50
Heating 8.60 3.5 - 9.1 1.88 0.56 - 2.71 8.30
3.2 + 3.2 +
3.2
Cooling 6.78 2.8 - 8.5 1.96 0.49 - 2.80 8.60
Heating 8.58 3.3 - 9.1 1.85 0.52 - 2.67 8.10
CU-4E27CBPG One-room
Operation
2.2 Cooling 2.20 1.9 - 2.7 0.45 0.38 - 0.62 2.25
Heating 3.20 1.7 - 4.7 0.84 0.37 - 1.83 3.85
2.8 Cooling 2.80 2.0 - 3.4 0.62 0.38 - 0.90 2.95
Heating 4.00 1.7 - 4.8 1.21 0.37 - 1.90 5.40
3.2 Cooling 3.20 2.0 - 3.9 0.72 0.38 - 1.09 3.40
Heating 4.50 1.7 - 5.8 1.31 0.37 - 2.29 5.85
4.0 Cooling 4.00 2.0 - 4.4 1.03 0.38 - 1.39 4.60
Heating 5.60 1.8 - 7.2 1.90 0.37 - 3.56 8.35
5.0 Cooling 5.00 2.1 - 5.2 1.61 0.40 - 1.80 7.15
Heating 7.10 2.1 - 7.3 2.84 0.43 - 3.56 12.40
Two-room
Operation
2.2 + 2.2 Cooling 4.40 2.1 - 5.0 0.98 0.40 - 1.26 4.45
Heating 6.40 1.8 - 9.4 1.48 0.40 - 3.55 6.50
2.2 + 2.8 Cooling 5.00 2.1 - 6.1 1.23 0.40 - 1.88 5.50
Heating 7.10 2.1 - 9.4 1.70 0.42 - 3.51 7.55
2.2 + 3.2 Cooling 5.40 2.2 - 7.0 1.37 0.40 - 2.79 6.10
Heating 7.50 2.2 - 9.8 1.74 0.42 - 3.49 7.65
2.2 + 4.0 Cooling 6.20 2.2 - 7.1 1.82 0.40 - 2.79 8.00
Heating 8.30 2.4 - 9.8 2.06 0.44 - 3.44 9.05
2.2 + 5.0 Cooling 7.00 2.5 - 7.2 2.50 0.46 - 2.80 11.00
Heating 8.80 3.2 - 9.9 2.26 0.53 - 3.40 9.90
2.8 + 2.8 Cooling 5.60 2.2 - 6.9 1.55 0.40 - 2.78 6.85
Heating 7.70 2.3 - 9.4 2.02 0.44 - 3.48 8.85
2.8 + 3.2 Cooling 6.00 2.2 - 7.0 1.70 0.40 - 2.79 7.55
Heating 8.10 2.4 - 9.8 1.98 0.44 - 3.46 8.70
2.8 + 4.0 Cooling 6.80 2.2 - 7.1 2.28 0.40 - 2.79 10.00
Heating 8.60 2.1 - 9.8 2.175 0.53 - 3.39 9.65
2.8 + 5.0 Cooling 7.10 2.5 - 7.2 2.61 0.46 - 2.80 11.50
Heating 9.00 3.2 - 9.9 2.39 0.53 - 3.37 10.50
3.2 + 3.2 Cooling 6.40 2.2 - 7.3 1.86 0.40 - 2.81 8.15
Heating 8.50 2.5 - 10.1 2.11 0.47 - 3.39 9.30
3.2 + 4.0 Cooling 7.00 2.5 - 7.3 2.41 0.46 - 2.81 10.60
Heating 8.80 3.2 - 10.1 2.23 0.53 - 3.34 9.85
3.2 + 5.0 Cooling 7.40 2.6 - 7.4 2.82 0.46 - 2.88 12.30
Heating 9.20 3.2 - 10.1 2.39 0.53 - 3.30 10.50
4.0 + 4.0 Cooling 7.20 2.5 - 7.3 2.62 0.46 - 2.81 11.50
Heating 9.10 3.2 - 10.1 2.36 0.53 - 3.32 10.30
4.0 + 5.0 Cooling 7.30 2.7 - 7.4 2.67 0.48 - 2.82 11.70
Heating 9.40 3.2 - 10.2 2.48 0.53 - 3.30 10.90
5.0 + 5.0 Cooling 7.50 2.8 - 7.6 2.86 0.48 - 2.87 12.50
Heating 9.40 3.5 - 10.2 2.47 0.59 - 3.29 10.90
Three-room
Operation
2.2 + 2.2 +
2.2
Cooling 6.60 2.2 - 7.8 1.66 0.41 - 2.49 7.40
Heating 8.61 3.1 - 10.4 1.99 0.50 - 3.25 8.80
2.2 + 2.2 +
2.8
Cooling 7.00 2.5 - 8.1 1.89 0.46 - 2.85 8.25
Heating 8.80 3.2 - 10.4 2.01 0.51 - 3.22 8.85
2.2 + 2.2 +
3.2
Cooling 7.30 2.5 - 8.2 1.98 0.46 - 2.79 8.70
Heating 8.90 3.2 - 10.4 2.03 0.51 - 3.22 8.95
2.2 + 2.2 +
4.0
Cooling 7.80 2.6 - 8.2 2.33 0.46 - 2.83 10.30
Heating 9.20 3.2 - 10.4 2.15 0.51 - 3.18 9.50
2.2 + 2.2 +
5.0
Cooling 8.00 2.8 - 8.3 2.46 0.49 - 2.82 10.80
Heating 9.40 3.2 - 10.4 2.12 0.51 - 3.18 9.30
2.2 + 2.8 +
2.8
Cooling 7.40 2.5 - 8.1 2.14 0.46 - 2.79 9.40
Heating 9.00 3.2 - 10.4 2.09 0.51 - 3.19 9.20
2.2 + 2.8 +
3.2
Cooling 7.60 2.6 - 8.2 2.24 0.46 - 2.84 9.85
Heating 9.20 3.2 - 10.4 2.11 0.51 - 3.18 9.30
2.2 + 2.8 +
4.0
Cooling 8.00 2.7 - 8.2 2.51 0.49 - 2.80 11.00
Heating 9.40 3.2 - 10.4 2.16 0.51 - 3.14 9.50
