Panasonic CS-E18DB4EW Service Manual

17.1.6. Replacement Parts List (Indoor Unit)
Models:
CS-E18DKEW / CS-E18DKRW / CS-E18DKDW
REF. NO. PART NAME & DESCRIPTION QTY. CS-E18DKEW CS-E18DKRW CS-E18DKDW REMARKS
1 CHASSY COMPLETE 1 CWD50C1382
←
←←
← ←
←←
←
2 FAN MOTOR 1 CWA981149
←
←←
← ←
←←
←
3 CROSS FOLW FAN COMPLETE 1 CWH02C1010
←
←←
← ←
←←
←
4 SCREW - CROSS FLOW FAN 1 CWH4580304
←
←←
← ←
←←
←
5 BEARING ASS’Y 1 CWH64K007
←
←←
← ←
←←
←
6 EVAPORATOR 1 CWB30C1533
←
←←
← ←
←←
←
7 FLARE NUT 1 CWT25086 (1/4")
←
←←
← ←
←←
←
8 FLARE NUT 1 CWT25096 (1/2")
←
←←
← ←
←←
←
9 HOLDER SENSOR 1 CWH32143
←
←←
← ←
←←
←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2441
←
←←
← ←
←←
←
11 VERTICAL VANE 15 CWE241088
←
←←
← ←
←←
←
12 CONNECTING BAR 1 CWE261025
←
←←
← ←
←←
←
13 AIR SWING MOTOR 1 CWA98260
←
←←
← ←
←←
←
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849
←
←←
← ←
←←
←
14 AIR SWING MOTOR 1 CWA98K1008
←
←←
← ←
←←
←
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3731
←
←←
← ←
←←
←
16 HORIZONTAL VANE 1 CWE241152A
←
←←
← ←
←←
←
17 HORIZONTAL VANE 1 CWE241153A
←
←←
← ←
←←
←
18 CAP - DRAIN TRAY 1 CWH52C1001
←
←←
← ←
←←
←
19 BACK COVER CHASSIS 1 CWD932162B
←
←←
← ←
←←
←
20 CONTROL BOARD CASING 1 CWH102250
←
←←
← ←
←←
←
21 TERMINAL BOARD COMPLETE 1 CWA28C2082
←
←←
← ←
←←
←
22 POWER SUPPLY CORD 1 —
←
←←
← ←
←←
←
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1670
←
←←
← ←
←←
←
24 INDICATOR COMPLETE 1 CWE39C1116
←
←←
← ←
←←
←
25 INDICATOR HOLDER 1 CWD932435
←
←←
← ←
←←
←
26 INDICATOR HOLDER 1 CWD932436
←
←←
← ←
←←
←
27 SENSOR COMPLETE 1 CWA50C2122
←
←←
← ←
←←
←
28 CONTROL BOARD TOP COVER 1 CWH131209
←
←←
← ←
←←
←
29 CONTROL BOARD FRONT COVER 1 CWH131210
←
←←
← ←
←←
←
30 REMOTE CONTROL COMPLETE 1 CWA75C2616
←
←←
← ←
←←
←
31 FRONT GRILLE COMPLETE 1 CWE11C3160
←
←←
← ←
←←
←
32 INTAKE GRILLE COMPLETE 1 CWE22C1159
←
←←
← ←
←←
←
33 GRILLE DOOR 1 CWE141076
←
←←
← ←
←←
←
34 AIR FILTER (L) 1 CWD001137
←
←←
← ←
←←
←
35 AIR FILTER (R) 1 CWD001138
←
←←
← ←
←←
←
36 SCREW - FRONT GRILLE 3 XTT4+16C
←
←←
← ←
←←
←
37 CAP - FRONT GRILLE 3 CWH521062A
←
←←
← ←
←←
←
38 DRAIN HOSE 1 CWH851063
←
←←
← ←
←←
←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
←
←←
← ←
←←
←
40 INSTALLATION PLATE 1 CWH36K1007
←
←←
← ←
←←
←
41 FULCRUM 2 CWH621047
←
←←
← ←
←←
←
42 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675
←
←←
← ←
←←
←
43 CASING - IONIZER 1 CWD932464
←
←←
← ←
←←
←
44 CASING - IONIZER 1 CWD932527
←
←←
← ←
←←
←
45 ION GENERATOR 1 CWH94C0001
←
←←
← ←
←←
←
46 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013
←
←←
← ←
←←
←
47 ELECTRONIC CONTROLLER SUPERSONIC 1 CWA743874
←
←←
← ←
←←
←
48 SUPER ALLERU BUSTER FILTER 1 CWD00C1133
←
←←
← ←
←←
←
49 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026
←
←←
← ←
←←
←
50 RRAME FR AIR FILTER SUPERSONIC 1 CWD011027
←
←←
← ←
←←
←
(Note)
•
• •
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
• •
•
“
” marked parts are recommended to be kept in stock.
191
