17.3.2. Replacement Parts List (Indoor Unit)
Models:
CS-ME10DTEG / CS-E15DTEW / CS-E18DTEW
REF NO. PART NAME & DESCRIPTION QTY. CS-ME10DTEG CS-E15DTEW CS-E18DTEW REMARKS
1 CHASSY COMPLETE 1 CWD50C1419
←
←←
← ←
←←
←
2 FAN MOTOR 1 CWA921158
←
←←
← ←
←←
←
3 SUPPORTER FAN MOTOR 2 CWD932270
←
←←
← ←
←←
←
4 BLOWER WHEEL ASS’Y 2 CWH01K1014
←
←←
← ←
←←
←
5 AIR GUIDER B.W. 2 CWD321046
←
←←
← ←
←←
←
6 CONTROL BOARD ASS’Y 1 CWH10K1055
←
←←
← ←
←←
←
7 FLARE NUT (1/2") 1 CWT251032
←
←←
← ←
←←
←
8 TERMINAL BOARD ASS’Y 1 CWA28K1036
←
←←
← ←
←←
←
10 ELECTRONIC CONTROLLER 1 CWA73C1774 CWA73C1771 CWA73C1772
11 SENSOR ASS’Y COMP. 1 CWA50C2157
←
←←
← ←
←←
←
12 LEAD WIRE FAN MOTOR 1 CWA67C4431
←
←←
← ←
←←
←
13 LEAD WIRE FAN MOTOR 1 CWA67C4474
←
←←
← ←
←←
←
14 EVAPORATOR 1 CWB30C1663
←
←←
←
CWB30C1661
15 SUPPORTER TUBE ASS’Y 1 CWD932259
←
←←
← ←
←←
←
16 FLARE NUT (1/4") 1 CWT25086
←
←←
← ←
←←
←
17 DRAIN PAN COMPLETE 1 CWH40C1023
←
←←
← ←
←←
←
18 TAP DRAIN TRAY 1 CWH401031
←
←←
← ←
←←
←
19 DISCHARGE GRILLE COMPLETE 1 CWE20C2223
←
←←
← ←
←←
←
20 DISCHARGE GRILLE 1 CWE201046
←
←←
← ←
←←
←
21 VANE - AIR SWING 1 CWE241124
←
←←
← ←
←←
←
22 CONNECTING BAR 2 CWE261052
←
←←
← ←
←←
←
23 CONNECTING BAR 2 CWE261053
←
←←
← ←
←←
←
24 VANE 14 CWE241126
←
←←
← ←
←←
←
25 AIR SWING MOTOR 1 CWA981085
←
←←
← ←
←←
←
26 INDICATOR COMP. 1 CWE39C1128
←
←←
← ←
←←
←
28 CONTROL BOARD CASING ASS’Y 1 CWH13K1015
←
←←
← ←
←←
←
31 INTAKE GRILLE COMPLETE 1 CWE22C1185
←
←←
← ←
←←
←
32 AIR FILTER 2 CWD001088
←
←←
← ←
←←
←
33 REMOTE CONTROL COMPLETE 1 CWA75C2610
←
←←
← ←
←←
←
36 DRAIN HOSE 1 CWH85284
←
←←
← ←
←←
←
37 INSTALLATION HOLDER 1 CWH361018
←
←←
← ←
←←
←
38 ACCESSORY COMPLETE 1 CWH82C1286
←
←←
← ←
←←
←
39 FULCRUM 3 CWH621030
←
←←
← ←
←←
←
40 FRONT GRILLE COMPLETE 1 CWE11C3209
←
←←
← ←
←←
←
41 STRING COMPLETE 1 CWH84C1006
←
←←
← ←
←←
←
(Note)
•
• •
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
• •
•
“
” marked parts are recommended to be kept in stock.
