15.2. CS-E18EKK CS-E21EKK
REF. NO. PART NAME & DESCRIPTION QTY. CS-E18EKK CS-E21EKK Remarks
1 CHASSY COMPLETE 1 CWD50C1399 ←
2 FAN MOTOR, DC 30W 3PH 1 CWA981172J ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010 ←
4 SCREW - CROSS FLOW FAN 1 CWH551146 ←
5 BEARING ASS’Y 1 CWH64K007 ← O
6 EVAPORATOR 1 CWB30C1830 ←
7 FLARE NUT (1/4) 1 CWT251030 ←
8 FLARE NUT (1/2) 1 CWT251032 ←
9 DISCHARGE GRILLE COMPLETE 1 CWE20C2487 ←
10 VERTICAL VANE 16 CWE241088 ←
11 CONNECTING BAR 1 CWE261025 ←
12 A.S.MOTOR, DC SINGLE 12V 300 OHM 1 CWA98260+MJ ← O
13 LEADWIRE - AIR SWING MOTOR 1 CWA67C3849 ←
14 A.S.MOTOR, DC SINGLE 12V 300 OHM 1 CWA98K1008 ← O
15 LEADWIRE - AIR SWING MOTOR 1 CWA67C3731 ←
16 HORIZONTAL VANE 1 CWE241152A ←
17 HORIZONTAL VANE 1 CWE241153A ←
18 CAP - DRAIN TRAY 1 CWH52C1001 ←
19 BACK COVER - CHASSIS 1 CWD932162C ←
20 CONTROL BOARD CASING 1 CWH102250B ←
21 TERMINAL BOARD COMPLETE 1 CWA28C2082J ← O
22 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1878 CWA73C1879 O
23 INDICATOR COMPLETE 1 CWE39C1143 ←
24 INDICATOR HOLDER 1 CWD932435 ←
25 INDICATOR HOLDER 1 CWD932436 ←
26 SENSOR COMPLETE 1 CWA50C2135 ← O
27 CONTROL BOARD TOP COVER 1 CWH131209 ←
28 CONTROL BOARD FRONT COVER 1 CWH131210 ←
29 CONTROL BOARD COVER COMPLETE 1 CWH13C1069 ←
30 REMOTE CONTROL COMPLETE 1 CWA75C2915 ← O
31 FRONT GRILLE COMPLETE 1 CWE11C3400 ← O
32 INTAKE GRILLE COMPLETE 1 CWE22C1159 ←
33 GRILLE DOOR 1 CWE141076 ←
34 AIR FILTER (L) 1 CWD001137 ←
35 AIR FILTER (R) 1 CWD001138 ←
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 3 CWH521062A ←
38 DRAIN HOSE 1 CWH851063 ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←
40 INSTALLATION PLATE 1 CWH36K1007 ←
41 FULCRUM 2 CWH621047 ←
42 SUPER ALLERU BUSTER FILTER 1 CWD00C1132 ←
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
62
CS-E18EKK CU-E18EKK / CS-E21EKK CU-E21EKK
