15.4. CU-E18EKK CU-E21EKK
REF NO. DESCRIPTION & NAME QTY. CU-E18EKK CU-E21EKK Remarks
1 CHASSY ASSY 1 CWD50K2145A ←
2 ANTI - VIBRATION BUSHING 3 CWH50077 ←
3 COMPRESSOR 1 5CS130XAD04 ← O
4 NUT - COMPRESSOR MOUNT 3 CWH56000J ←
5 SOUND PROOF MATERIAL 1 CWMG302302 ←
6 FAN MOTOR BRACKET 1 CWD541054 ←
7 FAN MOTOR, DC 40W 3PH 1 CWA981166J ← O
8 SCREW - FAN MOTOR BRACKET 2 CWH551060J ←
9 SCREW - FAN MOTOR MOUNT 3 CWH551106J ←
10 PROPELLER FAN ASS’Y 1 CWH03K1016 ←
11 NUT - PROPELLER FAN 1 CWH56053J ←
12 CONDENSER 1 CWB32C1738 CWB32C1739
13 TUBE ASS’Y (CAP. TUBE) 1 — CWT022997
14 TUBE ASS’Y (EXP. VALVE) 1 CWT023679 ←
15 4-WAYS VALVE 1 CWB001057 ← O
16 STRAINER 1 CWB11094 ←
17 ACCUMULATOR 1 CWB131024 ←
18 RECEIVER 1 CWB14011 —
19 HOLDER - COUPLING 1 CWH351056A ←
20 OIL SEPARATER ASS’Y 1 — CWB16K1008
21 3-WAYS VALVE (GAS) 1 CWB011338 ← O
22 2-WAYS VALVE (LIQUID) 1 CWB021292 ← O
23 SOUND PROOF BOARD 1 CWH151050A ←
24 SOUND PROOF MATERIAL 1 CWG302270 ←
25 SOUND PROOF MATERIAL 1 CWG302300 ←
26 TERMINAL COVER 1 CWH171001 ←
27 NUT - TERMINAL COVER 1 CWH7080300J ←
28 SENSOR COMPLETE (COM. TOP) 1 CWA50C2343 ← O
29 HOLDER SENSOR 3 CWH321010 ←
30 V-COIL COMPLETE (4-WAYS VALVE) 1 CWA43C2232 ← O
31 V-COIL COMPLETE (EXPAND VALVE) 1 CWA43C2141J ← O
32 SENSOR COMPLETE (COMP. DISC.) 1 CWA50C2345 ←
33 SENSOR COMPLETE 1 CWA50C2347 ← O
34 REACTOR 1 CWA421069 ← O
35 CONTROL BOARD (SIDE) 1 CWH102273A ←
36 TERMINAL BOARD ASS’Y 1 CWA28K1154 ← O
37 FUSE HOLDER 1 K3GB1PH00016 ←
38 FUSE CAP TERMINAL TYPE 1 K5D203BK0001 ←
39 CONTROL BOARD (TOP) 1 — —
40 CONTROL BOARD (BOTTOM) 1 CWH102282A ←
41 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1912R CWA73C1913R O
42 CONTROL BOARD COVER (TOP) 1 CWH131167 ←
43 CABINET SIDE PLATE (L) 1 CWE041097A ←
44 HANDLE 1 CWE161010 ←
45 CABINET SIDE PLATE (R) 1 CWE041176A ←
46 HANDLE 2 CWE16000E ←
47 CABINET FRONT PLATE CO. 1 CWE06K1053 ←
48 WIRE NET 1 CWD041041A ←
49 CABINET TOP PLATE 1 CWE031036A ←
50 CONTROL BOARD COVER (BOTTOM) 1 CWH131168 ←
51 CONTROL BOARD COVER (TOP) 1 CWH131184A ←
52 OPERATING INSTRUCTION 1 CWF565066 ←
53 INSTALLATION INSTRUCTION 1 CWF612884 ←
54 FLEXIBLE PIPE 1 CWH5850080 ←
55 PACKING 1 CWB81012 ←
(Note)
• All parts are supplied from PHAAM Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
64
CS-E18EKK CU-E18EKK / CS-E21EKK CU-E21EKK
[PHAAM] Printed in Malaysia
