73
<Model: CS-E24GKES, CS-E28GKE>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF NO. PART NAME & DESCRIPTION QTY. CS-E24GKES CS-E28GKE REMARKS
1 CHASSY COMPLETE 1 CWD50C1520 ←
2 FAN MOTOR 1 ARW51H8P30AC ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010 ←
4 SCREW - CROSS FLOW FAN 1 CWH551146 ←
5 BEARING ASS’Y 1 CWH64K007 ←
6 EVAPORATOR 1 CWB30C1678 ←
7 FLARE NUT 1 CWT251030 (1/4”) ←
8 FLARE NUT 1 CWT251033 (5/8”) ←
9 HOLDER SENSOR 1 CWH32143 ←
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2685 ←
11 VERTICAL VANE 15 CWE241088 ←
12 CONNECTING BAR 1 CWE261025 ←
13 AIR SWING MOTOR 1 CWA98260+MJ ← O
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849 ←
14 AIR SWING MOTOR 1 CWA98K1008 ← O
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C4445 ←
16 HORIZONTAL VANE 1 CWE241228 ←
17 HORIZONTAL VANE 1 CWE241229 ←
18 CAP - DRAIN TRAY 1 CWH521096 ←
19 BACK COVER CHASSIS 1 CWD932162B ←
20 CONTROL BOARD CASING 1 CWH102334 ←
21 TERMINAL BOARD COMPLETE 1 CWA28C2305 ← O
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2538 CWA73C2539 O
24 INDICATOR COMPLETE 1 CWE39C1174 ← O
25 INDICATOR HOLDER 1 CWD932818 ←
26 INDICATOR HOLDER 1 CWD932817 ←
27 SENSOR COMPLETE 1 CWA50C2122 ← O
28 CONTROL BOARD TOP COVER 1 CWH131209 ←
29 CONTROL BOARD FRONT COVER 1 CWH131210 ←
30 REMOTE CONTROL COMPLETE 1 CWA75C3008 ← O
31 FRONT GRILLE COMPLETE 1 CWE11C3695 ← O
32 INTAKE GRILLE COMPLETE 1 CWE22C1361 ← O
33 GRILLE DOOR 1 CWE141076 ←
34 E-ION FILTER 2 CWD00K1002 ←
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ ←
37 CAP - FRONT GRILLE 3 CWH521062A ←
38 DRAIN HOSE 1 CWH851063 ←
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 ←
40 INSTALLATION PLATE 1 CWH36K1007 ←
41 FULCRUM 2 CWH621073 ←
42 E-ION AIR PURIFYING SYSTEM 1 CWH14C5600 ←
43 ION-GENERATOR 1 CWH94C0014 ←
51 ELECTRONIC CONTROLLER - POWER 1 CWA744805 ← O
