<Model: CU-E24GKE, CU-E28GKE>
REF. NO. DESCRIPTION & NAME QTY. CU-E24GKE CU-E28GKE REMARKS
1 BASE PAN ASS’Y 1 CWD52K1098 ←
2 COMPRESSOR 1 5KD240XAA21 ← O
3 ANTI-VIBRATION BUSHING 3 CWH50055 ←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←
4a PACKING 3 CWB811017 ←
6 CONDENSER COMPLETE 1 CWB32C1995 CWB32C1997
8 DISCHARGE MUFFLER 1 CWB121013 ←
10 3-WAYS VALVE (GAS) 1 CWB011251 ←
11 4-WAYS VALVE 1 CWB001026J ←
12 2-WAYS VALVE (LIQUID) 1 CWB021330 ←
20 SOUND PROOF MATERIAL-COMP 1 CWG302245 ←
21 SOUND PROOF MATERIAL 1 CWG302246 ←
22 SOUND-PROOF BOARD ASS’Y 1 CWH151075 ←
23 V-COIL COMPLETE 1 CWA43C2169J ← O
24 V-COIL COMPLETE 1 CWA43C2058J CWA43C2128J O
25 SENSOR-OD TEMP./COIL 1 CWA50C2381 ←
26 SENSOR-COMP.DISCHARGE 1 CWA50C2214 ←
27 SENSOR-COMP.SUCT/DEFROST 1 CWA50C2185 ←
28 CABINET REAR PLATE 1 CWE02C1037 ←
29 CONTROL BOARD CASING 1 CWH10K1046 ←
31 TERMINAL BOARD ASS’Y 1 CWA28K1107 ←
32 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←
33 CAPACITOR-FAN MOTOR 1 DS441355NPQA ← O
34 ELECTRONIC CONTROLLER (P. SUPPLY) 1 CWA743402 CWA744289 O
38 ELECTRONIC CONTROLLER (NOISE FILTER) 1 CWA744495 ← O
44 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C2723R CWA73C2724R O
46 REACTOR 2 CWA421066 G0C423J00001
48 TERMINAL COVER 1 CWH171039A ←
49 NUT FOR TERMINAL COVER 1 CWH7080300J ←
50 BRACKET FAN MOTOR 1 CWD54K1034 ←
50a SCREW - BRACKET FAN MOTOR 2 CWH551040J ←
54 FAN MOTOR 1 CWA951510 ← O
54a SCREW-FAN MOTOR 4 CWH551040J ←
55 PROPELLER FAN 1 CWH001019 ←
56 NUT for PROPELLER FAN 1 CWH561038J ←
57 CABINET FRONT PLATE 1 CWE061118A ←
58 DISCHARGE GRILLE 1 CWE201073 ←
59 CABINET SIDE PLATE 1 CWE04K1019A ←
60 WIRE NET 1 CWD041102A ←
61 CABINET TOP PLATE COMPLETE 1 CWE03C1040 ←
66 CABINET FRONT PLATE COMPLETE 1 CWE06C1086 ←
67 HANDLE 3 CWE161008 ←
68 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT07K1350 CWT07K1334
70 EXPANSION VALVE 1 CWB051016J CWB051018J
71 DRAIN HOSE 1 CWH5850080 ←
72 PACKING - L. TUBE 1 CWB811010 ←
73 OPERATION INSTRUCTION 1 CWF565560 ←
74 BAG-COMPLETE (DRAIN ELBOW) 1 CWG87C2030 ←
75 INSTALLATION INSTRUCTION 1 CWF613120 ←
76 PIPE COVER (FRONT) 1 CWD601074A ←
77 PIPE COVER (BACK) 1 CWD601075A ←
78 STRAINER 2 CWB111032
←
79 RECEIVER 1 CWB14030 CWB14017
