12
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W 62 65
Output Power W 25 25
Speed Hi rpm 770 770
Moisture Removal L/h (Pt/h) 1.3 (2.7) 1.5 (3.2)
Indoor Airflow
QLo
Cool
m
3
/min (ft
3
/min)
5.6 (198) 4.9 (173)
Heat
m
3
/min (ft
3
/min)
6.0 (212) 5.3 (187)
Lo
Cool
m
3
/min (ft
3
/min)
6.5 (230) 6.0 (212)
Heat
m
3
/min (ft
3
/min)
7.2 (254) 7.1 (251)
Me
Cool
m
3
/min (ft
3
/min)
8.7 (307) 8.7 (307)
Heat
m
3
/min (ft
3
/min)
9.3 (328) 9.6 (339)
Hi
Cool
m
3
/min (ft
3
/min)
10.9 (385) 11.3 (400)
Heat
m
3
/min (ft
3
/min)
11.4 (400) 11.7 (410)
SHi
Cool
m
3
/min (ft
3
/min)
11.6 (410) 11.7 (410)
Heat
m
3
/min (ft
3
/min)
12.0 (424) 12.1 (427)
Outdoor Airflow Hi
Cool
m
3
/min (ft
3
/min)
33.9 (1200) 29.8 (1050)
Heat
m
3
/min (ft
3
/min)
33.9 (1200) 29.8 (1050)
Refrigeration Cycle
Control Device Check Valve & Capillary Tube Check Valve & Capillary Tube
Refrigerant Oil
cm
3
RB68A or Freol Alpha 68M (320) RB68A or Freol Alpha 68M (320)
Refrigerant Type g (oz) R410A, 830 (29.3) R410A, 950 (33.5)
Dimension Height (I/D / O/D) mm (inch) 290 (11-7/16) / 540 (21-9/32) 290 (11-7/16) / 540 (21-9/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 289 (11-13/32) 204 (8-1/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 33 (73) 9 (20) / 34 (75)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard Length m (ft) 5 (16.4) 5 (16.4)
Length Range (min - max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 16
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 15 x 17 2 x 15 x 21
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium Aluminium
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x FPI 1 x 20 x 19 2 x 24 x 17
Size (W x H x L) mm
32 x 508 x 708 36.4 x 504 x 713
684
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Outdoor Power Supply Outdoor Power Supply
Power Supply Cord A Nil Nil
Thermostat Electronic Control Electronic Control
Protection Device Electronic Control Electronic Control
MODEL INDOOR CS-E7LKEW, CS-XE7LKEW CS-E9LKEW, CS-XE9LKEW
OUTDOOR CU-E7LKE-3 CU-E9LKE-3
