5
2 Specifications
MODEL INDOOR CS-E7LKEW, CS-XE7LKEW CS-E9LKEW, CS-XE9LKEW
OUTDOOR CU-E7LKE CU-E9LKE
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.70 2.05 2.40 0.80 2.50 3.00
BTU/h 2390 6990 8180 2730 8530 10200
Kcal/h 600 1760 2060 690 2150 2580
Running Current A — 2.2 — — 2.5 —
Input Power W 170 470 580 175 535 730
Annual Consumption kWh — 235 — — 268 —
EER
W/W 4.12 4.36 4.14 4.57 4.67 4.11
Kcal/hW 3.53 3.74 3.55 3.94 4.02 3.53
Power Factor % — 93 — — 93 —
Indoor Noise (H / L / QLo)
dB-A 37 / 24 / 20 39 / 25 / 20
Power Level dB 53 / 40 / 36 55 / 41 / 36
Outdoor Noise (H / L)
dB-A 45 / - 46 / -
Power Level dB 60 / - 61 / -
Heating
Capacity
kW 0.70 2.80 4.00 0.80 3.40 5.00
BTU/h 2390 9550 13600 2730 11600 17100
Kcal/h 600 2410 3440 690 2920 4300
Running Current A — 3.0 — — 3.4 —
Input Power W 160 635 1.02k 165 735 1.30k
COP
W/W 4.38 4.41 3.92 4.85 4.63 3.85
Kcal/hW 3.75 3.80 3.37 4.18 3.97 3.31
Power Factor % — 92 — — 94 —
Indoor Noise (H / L / QLo)
dB-A 38 / 25 / 20 40 / 27 / 20
Power Level dB 54 / 41 / 36 56 / 43 / 36
Outdoor Noise (H / L)
dB-A 46 / - 47 / -
Power Level dB 61 / - 62 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 2.90 / 900 / 3.22 3.62 / 1.15k / 3.15
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 2.35 / 930 / 2.53 2.88 / 1.18k / 2.44
Max Current (A) / Max Input Power (W) 4.7 / 1.02k 5.8 / 1.30k
Starting Current (A) 3.0 3.4
Compressor
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (6-poles) Brushless (6-poles)
Output Power W 650 700
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W — —
Output Power W 40 40
Speed
QLo
Cool rpm 590 630
Heat rpm 630 670
Lo
Cool rpm 670 730
Heat rpm 730 820
Me
Cool rpm 860 950
Heat rpm 910 1030
Hi
Cool rpm 1050 1180
Heat rpm 1090 1240
SHi
Cool rpm 1110 1240
Heat rpm 1150 1280
