14
MODEL INDOOR CS-E12LKEW, CS-XE12LKEW
OUTDOOR CU-E12LKE-3
Performance Test Condition EUROVENT
Power Supply
Phase, Hz Single, 50
V 230
Min. Mid. Max.
Cooling
Capacity
kW 0.80 3.50 4.00
BTU/h 2730 11900 13600
Kcal/h 690 3010 3440
Running Current A — 4.1 —
Input Power W 185 905 1.18k
Annual Consumption kWh — 453 —
EER
W/W 4.32 3.87 3.39
Kcal/hW 3.73 3.33 2.92
Power Factor % — 96 —
Indoor Noise (H / L / QLo)
dB-A 42 / 28 / 20
Power Level dB 58 / 44 / 36
Outdoor Noise (H / L)
dB-A 48 / -
Power Level dB 63 / -
Heating
Capacity
kW 0.80 4.40 6.70
BTU/h 2730 15000 22800
Kcal/h 690 3780 5760
Running Current A — 5.1 —
Input Power W 175 1.09k 1.93k
COP
W/W 4.57 4.04 3.47
Kcal/hW 3.94 3.47 2.98
Power Factor % — 93 —
Indoor Noise (H / L / QLo)
dB-A 42 / 33 / 20
Power Level dB 58 / 49 / 36
Outdoor Noise (H / L)
dB-A 50 / -
Power Level dB 65 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.85 / 1.67k / 2.90
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.75 / 1.68k / 2.23
Max Current (A) / Max Input Power (W) 8.9 / 1.93k
Starting Current (A) 5.1
Compressor
Type Hermetic Motor
Motor Type Brushless (6-poles)
Output Power W 700
Indoor Fan
Type Cross-flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W —
Output Power W 40
Speed
QLo
Cool rpm 630
Heat rpm 670
Lo
Cool rpm 830
Heat rpm 1010
Me
Cool rpm 1040
Heat rpm 1150
Hi
Cool rpm 1260
Heat rpm 1300
SHi
Cool rpm 1320
Heat rpm 1340
