Panasonic CS-E7NKR Service Manual

14
Indoor CS-E15NKR
Model
Outdoor CU-E15NKR
Performance Test Condition AS
Phase, Hz Single, 50
Power Supply
V 230 240
Min. Mid. Max. Min. Mid. Max.
kW 0.90 4.40 5.00 0.90 4.40 5.00
BTU/h 3070 15000 17100 3070 15000 17100
Capacity
kcal/h 770 3780 4300 770 3780 4300
Running Current A - 5.5 - - 5.3 -
Input Power W 215 1.20k 1.60k 215 1.20k 1.60k
W/W 4.19 3.67 3.13 4.19 3.67 3.13
BTU/hW 14.28 12.50 10.69 14.28 12.50 10.69
EER
kcal/hW 3.58 3.15 2.69 3.58 3.15 2.69
Power Factor % - 95 - - 94 -
dB-A 45 / 30 / 23 45 / 30 / 23
Indoor Noise (H / L / QLo)
Power Level dB 61 / 46 / 39 61 / 46 / 39
dB-A 46 / - / 41 46 / - / 41
Cooling
Outdoor Noise (H / L / QLo)
Power Level dB 61 / - / 56 61 / - / 56
kW 0.90 5.50 5.60 0.90 5.50 5.60
BTU/h 3070 18800 19100 3070 18800 19100
Capacity
kcal/h 770 4730 4820 770 4730 4820
Running Current A - 6.7 - - 6.5 -
Input Power W 245 1.47k 1.53k 245 1.47k 1.53k
W/W 3.67 3.74 3.66 3.67 3.74 3.66
BTU/hW 12.53 12.79 12.48 12.53 12.79 12.48
COP
kcal/hW 3.14 3.22 3.15 3.14 3.22 3.15
Power Factor % - 95 - - 94 -
dB-A 43 / 31 / 27 43 / 31 / 27
Indoor Noise (H / L / QLo)
Power Level dB 59 / 47 / 43 59 / 47 / 43
dB-A 46 / - / 41 46 / - / 41
Heating
Outdoor Noise (H / L / QLo)
Power Level dB 61 / - / 56 61 / - / 56
Capacity kW 4.05
Input Power W 1.35k
H2
COP W/W 3.00
Capacity kW 7.10
Input Power W 2.25k
Powerful Heat
COP W/W 3.16
Max Current (A) / Max Input Power (W) 10.2 / 2.32k
Starting Current (A) 6.7
Type Hermetic Motor (Rotary)
Motor Type Brushless (6 poles)
Compressor
Output Power W 900
