Panasonic CS-E7NKR Service Manual

182
18.2 Sensible Capacity Chart
 CU-E7NKR
INDOOR OUTDOOR TEMPERATURE (°C DB)
CU-E7NKR
EWB EDB 20 25 30 32
%RH °C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI
51.8 14 20 1.99 1.98 0.36 2.01 1.91 0.39 1.95 1.89 0.42 1.91 1.87 0.43
54.1 16 22 2.10 1.95 0.36 2.10 1.88 0.39 2.03 1.86 0.42 1.99 1.86 0.44
50.0 17 24 2.17 1.97 0.36 2.17 1.91 0.39 2.10 1.90 0.43 2.06 1.89 0.44
50.9 18 25 2.20 2.02 0.36 2.19 1.96 0.39 2.13 1.94 0.43 2.08 1.94 0.44
47.1 19 27 2.24 2.11 0.36 2.24 2.08 0.39 2.18 2.03 0.43 2.13 2.03 0.44
50.1 22 30 2.38 2.03 0.36 2.38 1.98 0.40 2.32 1.97 0.43 2.27 1.96 0.44
51.9 24 32 2.47 1.97 0.37 2.48 1.92 0.40 2.41 1.91 0.43 2.37 1.91 0.44
INDOOR OUTDOOR TEMPERATURE (°C DB)
CU-E7NKR
EWB EDB 35 40 46
%RH °C °C TC SHC PI TC SHC PI TC SHC PI
51.8 14 20 1.83 1.83 0.45 1.64 1.64 0.49 1.18 1.18 0.53
54.1 16 22 1.92 1.81 0.46 1.73 1.73 0.49 1.37 1.37 0.53
50.0 17 24 2.00 1.85 0.46 1.80 1.78 0.49 1.37 1.37 0.53
50.9 18 25 2.02 1.89 0.46 1.82 1.82 0.49 1.44 1.44 0.53
47.1 19 27 2.05 1.99 0.46 1.86 1.86 0.49 1.56 1.56 0.53
50.1 22 30 2.21 1.94 0.46 2.00 1.88 0.50 1.84 1.84 0.54
51.9 24 32 2.30 1.88 0.47 2.09 1.83 0.50 1.67 1.67 0.54
 CU-E9NKR
INDOOR OUTDOOR TEMPERATURE (°C DB)
CU-E9NKR
EWB EDB 20 25 30 32
%RH °C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI
51.8 14 20 2.48 2.44 0.39 2.49 2.36 0.42 2.43 2.32 0.46 2.40 2.31 0.47
54.1 16 22 2.63 2.40 0.39 2.60 2.32 0.42 2.54 2.29 0.46 2.50 2.29 0.48
50.0 17 24 2.72 2.43 0.39 2.69 2.35 0.43 2.62 2.34 0.46 2.58 2.33 0.48
50.9 18 25 2.74 2.49 0.39 2.72 2.41 0.43 2.65 2.40 0.46 2.61 2.39 0.48
47.1 19 27 2.80 2.60 0.39 2.78 2.53 0.43 2.72 2.51 0.46 2.68 2.50 0.48
50.1 22 30 2.97 2.50 0.40 2.95 2.44 0.43 2.89 2.42 0.47 2.85 2.42 0.48
51.9 24 32 3.09 2.43 0.40 3.07 2.37 0.44 3.01 2.36 0.47 2.97 2.35 0.48
INDOOR OUTDOOR TEMPERATURE (°C DB)
CU-E9NKR
EWB EDB 35 40 46
%RH °C °C TC SHC PI TC SHC PI TC SHC PI
51.8 14 20 2.32 2.26 0.49 2.11 2.11 0.53 1.49 1.49 0.57
54.1 16 22 2.44 2.23 0.50 2.22 2.15 0.53 1.73 1.73 0.58
50.0 17 24 2.54 2.27 0.50 2.32 2.19 0.54 1.73 1.73 0.58
50.9 18 25 2.56 2.33 0.50 2.35 2.26 0.54 1.83 1.83 0.58
47.1 19 27 2.60 2.45 0.50 2.40 2.39 0.54 2.01 2.01 0.58
50.1 22 30 2.80 2.39 0.50 2.57 2.31 0.54 2.34 2.28 0.58
51.9 24 32 2.92 2.32 0.51 2.69 2.26 0.54 2.12 2.12 0.58
