Panasonic CS-E7NKR Service Manual

181
 Piping Length Characteristic
[Condition] Indoor temperature: 20/-°C, 7/6°C
Remote condition: High fan speed
Comp. Hz: F
h
6.500
7.000
7.500
8.000
8.500
9.000
9.500
2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
Piping Length (m)
Heating
Capacity (kW)
2.000
2.200
2.400
2.600
2.800
3.000
3.200
24681012141618202224262830
Piping Length (m)
Gas Side Piping Pressure (MPa
)
34.000
35.000
36.000
37.000
38.000
39.000
40.000
41.000
42.000
2 4 6 8 10 12 14 16 18 20 22 24 26 28 30
Piping Length (m)
Outlet Air
Temperature (°C
)
230 240
8.800
9.300
9.800
10.300
10.800
11.300
11.800
12.300
12.800
2 4 6 8 1012141618202224262830
Piping Length (m)
Current
(A)
