Panasonic CS-E7NKR Service Manual

6
Type Cross-Flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W 47.3 - 47.3
Output Power W 40
Cool rpm 630
QLo
Heat rpm 650
Cool rpm 710
Lo
Heat rpm 760
Cool rpm 900
Me
Heat rpm 950
Cool rpm 1090
Hi
Heat rpm 1150
Cool rpm 1190
Indoor Fan
Speed
SHi
Heat rpm 1250
Type Propeller Fan
Material PP
Motor Type DC Motor (8-poles)
Input Power W -
Output Power W 40
Cool rpm 790
Outdoor Fan
Speed Hi
Heat rpm 770
Moisture Removal L/h (Pt/h) 1.3 (2.7)
Cool m
3
/min (ft
3
/min) 5.33 (188)
QLo
Heat m
3
/min (ft
3
/min) 5.80 (205)
Cool m
3
/min (ft
3
/min) 6.38 (225)
Lo
Heat m
3
/min (ft
3
/min) 7.01 (247)
Cool m
3
/min (ft
3
/min) 8.44 (298)
Me
Heat m
3
/min (ft
3
/min) 9.10 (321)
Cool m
3
/min (ft
3
/min) 10.5 (370)
Hi
Heat m
3
/min (ft
3
/min) 11.3 (400)
Cool m
3
/min (ft
3
/min) 11.65 (411)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 12.40 (438)
Cool m
3
/min (ft
3
/min) 28.9 (1020)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 28.9 (1020)
Control Device Check Valve & Capillary Tube
Refrigerant Oil cm
3
FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 880 (31.1)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 824 (32-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 214 (8-7/16) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 32 (71)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 7.5 (24.6)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6)
