Panasonic CS-E9BKP Service Manual

8.1.3. Indoor Fan Motor Operation
There are 31 fan speed numbers assigned for different fan speed operation at designed conditions, as shown in below table. The
fan speed can be set manually using remote control (5 speeds for cooling mode: Lo, Me-, Me, Me+, Hi; 5 speeds for heating: Lo,
Me-, Me, Me+, Shi) or let it automatically changes depending on the operation and its environment.
Fan
Speed
No.
CS-E9BKP CS-E12BKP Remark
Voltage
(V)
Cooling Dry Heating Voltage
(v)
Cooling Dry Heating
0 OFF OFF OFF OFF OFF OFF - Hot start control.
- Deice control.
1
2 3.03 3.03
3 3.05 SLo 3.05 SLo - Soft Dry operation mode.
- ON timer pre-operation (D).
- Sleep shift operation (D).
4 3.13 3.13 - Auto operation mode judgment (C/D).
- ON timer preparation sampling (C/D).
5 3.15 3.23 - Auto operation mode judgment (H).
- ON timer preparation sampling (H).
- Sleep shift operation at compressor off.
6 3.16 Lo 3.29 Lo - Sleep shift operation (C).
- ON timer pre-operation at Auto fan (C).
7 3.23 Lo 3.34 - ON timer pre-operation at Auto fan for E9BKP
(H).
8 3.24 3.40
9 3.31 Me- 3.44 Me-
10 3.36 3.53
11 3.39 Me- 3.60 Me - Powerful Mode at Lo fan for E123BKP (C).
12 3.44 3.63
13 3.47 Me 3.66 Lo - Powerful Mode at Lo fan for E9BKP (C).
- ON timer pre-operation at Auto fan for E12BKP
(H).
14 3.55 Me 3.68 - Powerful Mode at Lo fan for E9BKP (H).
15 3.57 3.71
16 3.60 3.75 Me-
17 3.63 Me+ 3.77 Me+ - Powerful Mode at Me- fan (C).
18 3.66 3.83
19 3.68 3.85
20 3.71 3.86 Me - Powerful Mode at Lo fan for E12BKP (H).
21 3.73 Me+ 3.91 - Powerful Mode at Me- fan for E9BKP (H).
22 3.77 3.94
23 3.79 3.98 Me+ - Powerful Mode at Me- fan for E12BKP (H).
24 3.80 4.00
25 3.82 Hi 4.00 Hi - Powerful mode at Me, Me+ or Hi fan (C).
26 3.85 4.01
27 3.89 4.05
28 3.90 4.08
29 3.91 4.11
30 3.93 SHi 4.16 SHi - Powerful mode at Me, Me+ or Hi fan (H).
31 4.07 4.30
21
CS-E9BKP CU-E9BKP5 / CS-E12BKP CU-E12BKP5
