Panasonic CS-E9HKEA Service Manual

4
2 Specifications
2.1. CS-E9HKEA CU-E9HKEA
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 2.60 (0.60 ~ 3.00)
kCal/h 2240 (520 ~ 2580)
EER
W/W 4.41 (5.00 ~ 4.00)
kCal/hW 3.80 (4.33 ~ 3.44)
Noise Level
dB (A) High 39, Low 26, Q-Lo 23 High 46
Power level dB 50 59
H
E
A
T
I
N
G
Capacity
kW 3.60 (0.60 ~ 5.40)
kCal/h 3100 (520 ~ 4640)
COP
W/W 4.26 (5.22 ~ 3.97)
kCal/hW 3.67 (4.52 ~ 3.41)
Noise Level
dB (A) High 40, Low 27, Q-Lo 24 High 47
Power level dB 51 60
Moisture Removal
l/h 1.6
pt/h 3.4
Air Volume
Lo
m
3
/min (ft
3
/min)
Cooling; 4.9 (174)
—
Heating; 5.4 (192)
Me
m
3
/min (ft
3
/min)
Cooling; 7.1 (252)
—
Heating; 8.0 (283)
Hi
m
3
/min (ft
3
/min)
Cooling; 9.6 (339)
Cooling; 29.8 (1050)
Heating; 10.5 (370)
SHi
m
3
/min (ft
3
/min)
Cooling; 9.9 (350)
—
Heating; 10.9 (384)
Refrigeration Control Device — Exp. Valve
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (400)
Refrigerant (R410A) g (oz) — 930 (32.8)
Dimension
Height mm (inch) 280 (11-1/32) 540 (21-9/32)
Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-13/32)
Net Weight kg (lbs) 9 (20) 35 (77)
Pipe Diameter
Gas mm (inch) 9.52 (3/8)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (4-pole)
Rated Output W — 750
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (8-pole)
Output Power W 30 40
Fan Speed
Lo (Cool/Heat) rpm 820 / 880 —
Me (Cool/Heat) rpm 1050 / 1140 —
Hi (Cool/Heat) rpm 1280 / 1400 800 / 790
SHi (Cool/Heat) rpm 1320 / 1440 —
