Panasonic CS-E9HKEA Service Manual

6
2.2. CS-E12HKEA CU-E12HKEA
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 3.50 (0.60 ~ 4.00)
kCal/h 3010 (520 ~ 3440)
EER
W/W 3.80 (5.00 ~ 3.39)
kCal/hW 3.27 (4.33 ~ 2.92)
Noise Level
dB (A) High 42, Low 29, Q-Lo 26 High 48
Power level dB 53 61
H
E
A
T
I
N
G
Capacity
kW 4.80 (0.60 ~ 6.60)
kCal/h 4130 (520 ~ 5680)
COP
W/W 3.81 (5.22 ~ 3.57)
kCal/hW 3.28 (4.52 ~ 3.07)
Noise Level
dB (A) High 42, Low 33, Q-Lo 30 High 50
Power level dB 53 63
Moisture Removal
l/h 2.0
pt/h 4.2
Air Volume
Lo
m
3
/min (ft
3
/min)
Cooling; 5.8 (204)
—
Heating; 7.4 (261)
Me
m
3
/min (ft
3
/min)
Cooling; 8.1 (286)
—
Heating; 9.3 (328)
Hi
m
3
/min (ft
3
/min)
Cooling; 10.7 (377)
Cooling; 31.0 (1090)
Heating; 11.2 (395)
SHi
m
3
/min (ft
3
/min)
Cooling; 10.8 (381)
—
Heating; 11.59 (409)
Refrigeration Control Device — Exp. Valve
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (400)
Refrigerant (R410A) g (oz) — 970 (34.2)
Dimension
Height mm (inch) 280 (11-1/32) 540 (21-9/32)
Width mm (inch) 799 (31-15/32) 780 (30-23/32)
Depth mm (inch) 183 (7-7/32) 289 (11-13/32)
Net Weight kg (lbs) 9 (20) 35 (77)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (4-pole)
Rated Output W — 750
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG20K1 PP
Motor Type Transistor (8-pole) Induction (8-pole)
Output Power W 30 40
Fan Speed
Lo (Cool/Heat) rpm 910 / 1080 —
Me (Cool/Heat) rpm 1165 / 1290 —
Hi (Cool/Heat) rpm 1420 / 1500 840 / 820
SHi (Cool/Heat) rpm 1460 / 1540 —
