16.2. Sensible Capacity Chart
CS-E9HKEA CU-E9HKEA
230V Outdoor Temp. (qC)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0qC 2.58 1.96 0.54 2.41 1.88 0.58 2.24 1.80 0.62 2.04 1.71 0.67
19.0qC 2.60 0.59
19.5qC 2.83 2.05 0.55 2.65 1.97 0.59 2.46 1.89 0.63 2.24 1.80 0.68
22.0qC 3.09 2.12 0.56 2.88 2.04 0.60 2.68 1.97 0.64 2.44 1.88 0.70
CS-E12HKEA CU-E12HKEA
230V Outdoor Temp. (qC)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0qC 3.47 2.63 0.84 3.24 2.52 0.91 3.02 2.43 0.97 2.74 2.30 1.05
19.0qC 3.50 0.92
19.5qC 3.81 2.76 0.86 3.56 2.65 0.92 3.31 2.55 0.99 3.01 2.43 1.07
22.0qC 4.15 2.86 0.87 3.88 2.75 0.94 3.61 2.65 1.01 3.28 2.53 1.08
TC
SHC
IP
-
-
-
Total Cooling Capacity (kW)
Sensible Heat Capacity (kW)
Input Power (kW)
Indoor 27qC/19qC
Outdoor 35qC/24qC

Panasonic CS-E9HKEA Specifications

General

Cooling Capacity	2.5 kW
Heating Capacity	3.2 kW
Power Supply	220-240V, 50Hz
Refrigerant	R32
Weight (Indoor Unit)	8 kg
Type	Split System
Indoor Unit Noise Level	19 dB
