118
19 Replacement Part List (Outdoor Unit)
19.1. CU-J14DBE5 CU-J18DBE5
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
NO. PART DESCRIPTION QTY. CU-J14DBE5 CU-J18DBE5
1 BASE PAN ASS’Y 1 CWD52K1159 ←
2 COMPRESSOR 1 5KS150DBN21 5KS205DAH21
3 ANTI-VIBRATION BUSHING 3 CWH50055 ←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←
5 GASKET FOR TERMINAL COVER 3 CWB811017 ←
6 CRANKCASE HEATER 1 CWA341033 ←
7 CRANKCASE HEATER 1 - CWA341035
8 CONDENSER COMPLETE 1 CWB32C1808 CWB32C1810
9 PIPE HOLDER RUBBER 1 CWG251022 ←
10 HEATING PRESSURE SWITCH 1 CWA101007 ←
11 TUBE ASS’Y(EXP.VALVE AND STRAINER) 1 CWT024344 CWT024345
12 3-WAYS VALVE(LIQUID) 1 CWB011423 ←
13 3-WAYS VALVE(GAS) 1 CWB011425 ←
14 STRAINER 2 CWB111032 ←
15 HOLDER-SERVICE VALVE 1 CWD911425 ←
16 SOUND PROOF BOARD 1 CWH151078 ←
17 SOUND PROOF MATERIAL 1 CWG302338 ←
18 V-COIL COMPLETE 1 CWA43C2128J ←
19 PIPING SENSOR 1 CWA50C2292 ←
20 PIPING SENSOR 1 CWA50C2293 ←
21 SPRING FOR SENSOR 2 CWH711010 ←
22 CABINET REAR PLATE COMPLETE 1 CWE02C1035 ←
23 CONTROL BOARD ASS’Y 1 CWH10K1063 ←
24 TERMINAL BOARD ASS’Y 1 CWA28K1085J ←
25 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←
26 CAPACITOR-FM (2.0µF/460V) (2.5µF/460V) 1 DS461205QP-A DS461255QP-A
27 CAPACITOR-COMP. (30µF/370V) (50µF/370V) 1 DS371306CPNA DS371506CPNA
28 HOLDER CAPACITOR 1 CWH30176 CWH30060
29 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1890 CWA73C1891
30 MAGNETIC RELAY 1 K6C2A9A00001 K6C4E8A00003
31 TRANSFORMER 1 CWA401060 ←
32 TERMINAL COVER 1 CWH171011 CWH171012
33 NUT FOR TERMINAL COVER 1 CWH7080300J ←
34 BRACKET FAN MOTOR ASS’Y 1 CWD54K1025 ←
35 SCREW-FAN MOTOR BRACKET 2 CWH551040J ←
36 FAN MOTOR AC 70W SINGLE 1 CWA951366J ←
37 SCREW-FAN MOTOR 4 CWH551040J ←
38 PROPELLER FAN 1 CWH001019 ←
39 NUT-PROPELLER FAN 1 CWH561038J ←
40 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ←
41 PIPE COVER (FRONT) 1 CWD601074A ←
42 PIPE COVER (BACK) 1 CWD60K1003A ←
43 CABINET FRONT PLATE 1 CWE061118A ←
44 DISCHARGE GRILLE 1 CWE201073 ←
45 CABINET SIDE PLATE ASSY 1 CWE04K1019A ←
46 WIRE NET 1 CWD041063A ←
47 CABINET FRONT PLATE COMPLETE 1 CWE06C1131 ←
48 HANDLE 3 CWE161008 ←
49 LEADWIRE-COMPRESSOR-O.L.P 1 CWA67C6287 ←
50 WIRING COVER AND BAND 1 CWH82C1105 ←
51 INSTALLATION INSTRUCTION 1 CWF613006 ←
To Next Page
