Panasonic CS-F14DB4E5 Service Manual

40
Air conditioner body gap setting between ceiling surface should be 10mm as right figure.
(Adjustment of height direction should be done after fixing decorative panel.)
POSITIONS OF AIR CONDITIONER BODY AND CEILING SURFACE
Warning
Tighten the nuts and bolt to prevent unit from falling.
HANGING POSITION OF THE AIR CONDITIONER BODY
