Panasonic CS-F14DB4E5

44
• Remove the mounting screw, remove the control box cover, and then connect the wires by following the procedure given in the
illustration.
Earth lead wire shall be longer than other lead wires as shown in the figure for the electrical safety in case of the slipping out of the
cord from anchorage.
CONNECTING THE WIRES TO THE CONTROL BOX
Caution Make sure that screws of the terminal are securely tightened.
