10
3.2. CS-F24DB4E5 CU-J24DBE8
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F24DB4E5 CU-J24DBE8
Panel CZ-BT03P
Remote
Control
CZ-RD513C (Wired)
CZ-RL013B (Wireless)
Cooling Capacity kW 6.6
BTU/h 22,500
Refrigerant Charge-less m 30
Standard Air Volume for High,
m
3
/min
18 60
cfm 636 2120
Outside Dimension (H x W x D) mm 246 x 840 x 840 795 x 900 x 320
inch 9-11/16 x 33-1/24 x 33-1/24 31-5/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 26 (58) 61 (135)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain mm O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 1.8
Fan Type, Number of Set Turbo fan-1 Mix flow fan,1
Motor Type 8-pole DC motor 6-pole single phase induction motor
Rated Output kW 0.04 0.07
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (2 x 10 x 20) Corrugate-fin type (1 x 36 x 21)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged)
cm
3
- FV50S (1130)
Refrigerant (Charged) R410a kg (oz) - 1.35 (48)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 36/32 50/-
Power Level
dB
Cooling: 51/47 66/-
Moisture Removal L/h (Pt/h) 3.8 (8.0)
EER W/W 2.61/2.56/2.51
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase Three Three Three
Power Consumption kW Cooling 2.53 2.58 2.63
Running Current A Cooling 4.5 4.55 4.6
Starting Current A 23 25 27
Power Factor % Cooling 85 82 80
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3~380V, 400V, 415V 50Hz
To Next Page
