143
21 Replacement Part List (Outdoor Unit)
21.1. CU-J34DBE5 CU-J34DBE8 CU-J43DBE8 CU-J50DBE8
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
NO. PART DESCRIPTION QTY. CU-J34DBE5 CU-J34DBE8 CU-J43DBE8 CU-J50DBE8
1 BASE PAN ASS’Y 1 CWD52K1103 ←←←
2 COMPRESSOR 1 JT125G-P4V1 JT125G-P4Y1 JT160G-P4Y1 JT170G-P4Y1
3 ANTI-VIBRATION BUSHING 3 CWH501081 ←←←
4 NUT FOR COMP. MOUNT. 3 CWH561049 ←←←
5 CRANKCASE HEATER 1 CWA341025 ←←←
6 CONDENSER COMPLETE 1 CWB32C1709 ← CWB32C1691 ←
11 HEATING PRESSURE SWITCH 1 CWA101013 ←←←
12 3-WAYS VALVE (GAS) 1 CWB011251 ←←←
13 STRAINER 1 CWB111036 ←←←
14 PRESSURE SWITCH 1 CWA101012 ←←←
15 3-WAYS VALVE(LIQUID) 1 CWB011292 ←←←
16 TUBE ASS’Y(EXP.VALVE AND
STRAINER)
1 CWT023951 ←←←
17 RECEIVER 1 CWB141027 ←←←
18 SOUND-PROOF MATERIAL 1 CWG302335 ←←←
19 SOUND PROOF MATERIAL 1 CWG302336 ←←←
21 V-COIL COMPLETE 1 CWA43C2177J ←←←
22 HOLDER-SERVICE VALVE 1 CWD911425 ←←←
23 SOUND-PROOF BOARD 1 CWH151079 ←←←
24 PIPE SENSOR (COIL) 1 CWA50C2293 ←←←
25 PIPE SENSOR (DISCHARGE) 1 CWA50C2294 ←←←
26 SPRING FOR SENSOR 2 CWH711010 ←←←
27 CABINET REAR PLATE COMPLETE 1 CWE02C1030 ←←←
28 CONTROL BOARD ASS’Y 1 CWH10K1063 CWH10K1064 ←←
29 TERMINAL BOARD ASS’Y 1 CWA28K1085J CWA28K1109 ←←
30 TERMINAL BOARD ASS’Y 1 CWA28K1076J ←←←
31 CAPACITOR-FM (3.OmF/460)(3.5mF/
460V)
2 DS461305QP-A ←←DS461355QP-A
32 ELECTRO MAGNETIC SWITCH 1 K6C5E8A00001 K6C3A8A00001 ←←
33 ELECTRONIC CONTROLLER (MAIN) 1 CWA73C1896 CWA73C1897 CWA73C1898 CWA73C1899
34 TRANSFORMER 1 CWA401060 ←←←
35 BRACKET FAN MOTOR ASS’Y 1 CWD54K1019 ← CWD54K1023 ←
36 SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←←
37 FAN MOTOR AC 70W SINGLE 1 CWA951366 ←←←
39 FAN MOTOR AC 70W SINGLE 1 CWA951403 ←←←
39 SCREW-BRACKET FAN MOTOR 2 CWH551040J ←←←
40 PROPELLER FAN ASS’Y 2 CWH03K1017 ←←←
41 NUT for PROPELLER FAN 2 CWH561038J ←←←
42 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ←←←
43 PIPE COVER (FRONT) 1 CWD601074A ←←←
44 PIPE COVER (BACK) 1 CWD60K1003A ←←←
45 CABINET FRONT PLATE 1 CWE061092A ←←←
46 DISCHARGE GRILLE 2 CWE201075 ←←←
47 CABINET SIDE PLATE ASS’Y 1 CWE04K1022A ←←←
48 WIRE NET 1 CWD041064A ←←←
49 CABINET FRONT PLATE COMPLETE 1 CWE06C1132 ←←←
50 HANDLE 2 CWE161008 ←←←
51 LEADWIRE-COMPRESSOR 1 CWA67C5903 ←←←
52 WIRING COVER AND BAND 1 CWH82C1105 ←←←
53 INSTALLATION INSTRUCTION 1 CWF612864
←←←
55 CAPACITOR-COMP (35mF/370V) 1 DS441356CPNE - - -
56 HOLDER CAPACITOR 1 CWH30176 - - -
To Next Page
