3.8. CS-F50DTE5 CU-J50DBE8
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F50DTE5 CU-J50DBE8
Remote
Control
CZ-RD513C (Wired)
CZ-RL513T (Wireless)
Cooling Capacity kW 13.5
BTU/h 46,000
Refrigerant Charge-less m 30
Standard Air Volume for High Speed
m
3
/min
32 96
cfm 1130 3387
Outside Dimension (H x W x D) mm 250 x 1600 x 700 1170 x 900 x 320
inch 9-27/32 x 62-31/32 x 27-9/16 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 47 (104) 97 (214)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain
Compressor Type, Number of Set - Hermetic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 4.50
Fan Type, Number of Set Sirocco fan-4 Propeller fan-2
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.14 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Slit-fin type (3 x 14 x 18) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged)
cm
3
- DAPHNE FVC68D (1500)
Refrigerant (Charged) R22 kg (oz) - 3.25 (114)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 50/46 56/-
Power Level
dB
Cooling: 67/63 70/-
Moisture Removal L/h (Pt/h) 8.6 (18.1)
EER W/W 2.58/2.56/2.53
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase Three Three Three
Power Consumption kW Cooling 5.23 5.28 5.33
Running Current A Cooling 8.4 8.6 8.8
Starting Current A 55 58 61
Power Factor % Cooling 95 89 84
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3~380V, 400V, 415V 50Hz
