Panasonic CS-F34DD2E5 Service Manual

NO. PART DESCRIPTION QTY. CU-B24DBE5 CU-B28DBE5 CU-B28DBE8
1 BASE PAN ASSY 1 CWD52K1102 ← ←
2 COMPRESSOR 1 5JS315DAM21 5JS330DAF21 5JS330PBA21
3 ANTI-VIBRATION BUSHING 3 CWH50055 ← ←
4 NUT-COMPRESSOR MOUNT 3 CWH561049 ← ←
5 PACKING 3 CWB811017 ← ←
6 CRANKCASE HEATER 1 CWA341017 ← ←
7 CONDENSER COMPLETE 1 CWB32C1706 CWB32C1716 ←
8 TUBE ASSY (CAPILLARY TUBE) 1 CWT07K1306 CWT07K1302 ←
9 PIPE HOLDER RUBBER 1 CWG251016 ← ←
10 4-WAYS VALVE COMPLETE 1 CWB00C1031 ← ←
11 DISCHARGE MUFFLER 1 CWB121013 ← ←
12 4-WAYS VALVE 1 CWB001026J ← ←
13 HEATING PRESSURE SWITCH 1 CWA101007 ← ←
14 TUBE ASSY (STRAINER, EXP.VALVE) 1 CWT024068 CWT024146 ←
15 3-WAYS VALVE (LIQUID) 1 CWB011252 ← ←
16 3-WAYS VALVE (GAS) 1 CWB011251 ← ←
17 TUBE RECEIVER 1 CWB141031 ← ←
18 STRAINER 2 CWB111032 ← ←
19 PIPE HOLDER RUBBER 1 CWG251016 ← ←
20 HOLDER-SERVICE VALVE 1 CWD911425 ← ←
21 SOUND-PROOF BOARD 1 CWH151078 ← ←
22 TUBE RECEIVER 1 CWB14K1014A ← ←
23 SOUND PROOF MATERIAL 1 CWG302338 ← ←
24 V-COIL COMPLETE 1 CWA43C2169 ← ←
25 V-COIL COMPLETE 1 CWA43C2128J ← ←
26 PIPING SENSOR 1 CWA50C2292 ← ←
27 PIPING SENSOR 1 CWA50C2293 ← ←
28 SPRING FOR SENSOR 2 CWH711010 ← ←
29 CABINET REAR PLATE COMPLETE 1 CWE02C1029 ← ←
30 CONTROL BOARD ASSY 1 CWH10K1063 ← CWH10K1064
31 TERMINAL BOARD ASSY 1 CWA28K1085J ← CWA28K1109
32 TERMINAL BOARD ASSY 1 CWA28K1076J ← ←
33 CAPACITOR-FM (3.0µF/460V)(3.5µF/460V) 1 DS461305QP-A DS461355QP-A ←
34 CAPACITOR-COMP (45µF/370V)(50µF/370V) 1 DS371456CPNA DS371506CPNA -
35 HOLDER CAPACITOR 1 CWH30060 ← -
36 ELECTRONIC CONTROLLER-MAIN 1 CWA73C1902 CWA73C1904 CWA73C1905
37 MAGNETIC RELAY 1 K6C2A9A00001 ← -
38 TRANSFORMER 1 CWA401060 ← ←
39 TERMINAL COVER 1 CWH171012 ← CWH17015
40 NUT FOR TERMINAL COVER 1 CWH7080300J ← ←
41 BRACKET FAN MOTOR ASSY 1 CWD54K1010 ← ←
42 SCREW-FAN MOTOR BRACKET 2 CWH551040J ← ←
43 FAN MOTOR AC 70W SINGLE 1 CWA951366 ← ←
44 SCREW-FAN MOTOR BRACKET 4 CWH551040J ← ←
45 PROPELLER FAN 1 CWH001019 ← ←
46 NUT-PROPELLER FAN 1 CWH561038J ← ←
47 CABINET TOP PLATE COMPLETE 1 CWE03C1039 ← ←
48 PIPE COVER (FRONT) 1 CWD601074A ← ←
49 PIPE COVER (BACK) 1 CWD601081A ← ←
50 CABINET FRONT PLATE 1 CWE061118A ← ←
51 DISCHARGE GRILLE 1 CWE201073 ← ←
52 CABINET SIDE PLATE ASSY 1 CWE04K1019A ← ←
53 WIRE NET 1 CWD041063A ← ←
54 CABINET FRONT PLATE COMPLETE 1 CWE06C1147 ← ←
55 HANDLE 3 CWE161008 ← ←
56 LEADWIRE-COMPRESSOR 1 CWA67C5994 ← CWA67C5909
57 WIRING COVER AND BAND 1 CWH82C1105 ← ←
58 INSTALLATION INSTRUCTION 1 CWF612864 ← ←
59 ACCESSORY COMP. (DRAIN ELBOW) 1 CWG87C2030 ← ←
60 ELECTRO MAGNETIC SWITCH 1 - - K6C4E8A00003
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061)
