Panasonic CS-F50DB4E5

50
10.3. Position of the centre gravity
MODEL NAME OUTSIDE DIMENSIONS NET WEIGHT CENTRE OF GRAVITY
WIDTH (mm) DEPTH (mm) HEIGHT (mm) kg X (mm) Y (mm) Z (mm)
CU-B24DBE5 900 320 795 69 560 150 320
CU-B28DBE5 900 320 795 69 560 150 320
CU-B28DBE8
CU-B34DBE5 900 320 1170 102 560 150 450
CU-B34DBE8 100
CU-B43DBE8 900 320 1170 102 560 150 450
CU-B50DBE8 900 320 1170 102 560 150 450
