72
11.2.3. Fan performance
11.2.3.1. CS-F50MD1E5
Fan performance test report
Fan performance curve
Model
External
Pressure (Pa)
Fan speed Current (A)
Power
consumption
(kW)
Air volume
(m
3
/min)
CS-F50MD1E5
98 Hi 2.67 0.62 60
85 Me 2.25 0.53 53
75 Lo 1.96 0.46 46
65 SLo 1.71 0.40 39
