6
2.2. CS-HE12GKE CU-HE12GKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 3.50 (0.60 ~ 4.00)
kCal/h 3010 (520 ~ 3440)
EER
W/W 4.12 (5.00 ~ 3.81)
kCal/hW 3.54 (4.33 ~ 3.28)
Noise Level
dB-A (H/L/Q-Lo) 42 / 29 / 26 High 48
Power level dB 55 61
H
E
A
T
I
N
G
Capacity
kW 4.80 (0.60 ~ 7.70)
kCal/h 4130 (520 ~ 6620)
COP
W/W 4.62 (5.22 ~ 3.38)
kCal/hW 3.97 (4.52 ~ 2.90)
Noise Level
dB-A (H/L/Q-Lo) 44 / 33 / 30 High 50
Power level dB 55 63
Moisture Removal
l/h 2.0
pt/h 4.2
Air Volume
Q-Lo
m
3
/min (ft
3
/min)
Cooling; 6.2 (219)
—
Heating; 6.9 (244)
Lo
m
3
/min (ft
3
/min)
Cooling; 7.0 (247)
—
Heating; 8.0 (282)
Me
m
3
/min (ft
3
/min)
Cooling; 8.7 (307)
—
Heating; 10.8 (381)
Hi
m
3
/min (ft
3
/min)
Cooling; 11.3 (400) Cooling; 23.8 (840)
Heating; 13.5 (480) Heating; 23.8 (840)
Refrigeration Control Device — Check Valve & Capillary Tube
Refrigeration Oil
cm
3
— RB68A or Freol Alpha68M (400)
Refrigerant (R410A) g (oz) — 1330 (46.9)
Dimension
Height mm (inch) 298 (11-23/32) 540 (21-1/4)
Width mm (inch) 870 (34-1/4) 780 (30-23/32)
Depth mm (inch) 199 (7-27/32) 289 (11-3/8)
Net Weight kg (lbs) 12 (26) 37 (82)
Pipe Diameter
Gas mm (inch) 12.7 (1/2)
Liquid mm (inch) 6.35 (1/4)
Standard Length m (ft) 7.5 (24.6)
Pipe Length Range m (ft) 3 (9.8) ~ 15 (49.2)
Height Difference m (ft) 5 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Refrigeration Charge Less m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type — Hermetic Motor
Motor Type — Brushless (6-pole)
Rated Output W — 1.10k
Fan
Type Cross-Flow Fan Propeller Fan
Material ASG30K1 PP
Motor Type Transistor (8-pole) Induction (6-pole)
Input Power W 25 70
Output Power W 30 40
Fan Speed
Q-Lo (Cool/Heat) rpm 670 / 780 —
Lo (Cool/Heat) rpm 740 / 870 —
Me (Cool/Heat) rpm 920 / 1090 790 / -
Hi (Cool/Heat) rpm 1180 / 1310 —
