(Note)
•
“O” marked parts are recommended to be kept in stock.
17 Replacement Parts List
<Model: CS-MC76KE / CS-MC95KE>
NO. DESCRIPTION & NAME Q’TY CS-MC76KE CS-MC95KE REMARKS
1 CHASSY COMPLETE 1 CWD50C338
←
2 PARTICULAR PIECE 1 CWD931019
←
3 FAN MOTOR 1 CWA921033 CWA921034 0
4 LEAD WIRE - FAN MOTOR 1 CWA67C2097
←
5 CROSS FLOW FAN 1 CWH02C060
←
6 BEARING 1 CWH64K007
←
7 SCREW - CROSS FLOW FAN 1 CWH4580304
←
8 EVAPORATOR & TUBE ASS’Y COMPLETE 1 CWB30C1058 CWB30C1061
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
←
10 ANTI VIBRATION BUSHING 1 — CWH50211
11 FLARE NUT (1/4”) 1 CWH6002140
←
12 FLARE NUT (3/8”) 1 CWT25005
←
13 DISCHARGE GRILLE COMPLETE 1 CWE20C2062
←
14 VERTICAL VANE WITH TAB 2 CWE24458
←
15 VERTICAL VANE 10 CWE24457
←
16 CONNECTING BAR 2 CWE26194
←
17 AIR SWING MOTOR 1 CWA98260
←
0
18 LEAD WIRE - AIR SWING MOTOR 1 CWA67C2106
←
19 CAP FOR DRAIN TRAY 1 CWH52C003
←
20 HORIZONTAL VANE 1 CWE241027
←
21 CONTROL BOARD 1 CWH10965
←
22 POWER SUPPLY CORD 1 CWA20C2102
←
23 ELECTRONIC CONTROLLER 1 CWA742323
←
0
24 RECEIVER 1 CWA74919
←
0
25 INDICATOR COMPLETE 1 CWE39C1024
←
26 LEAD WIRE - INDICATOR 1 CWA67C2105
←
0
27 TERMINAL BOARD 1 CWA28C2028
←
0
28 INDICATOR HOLDER 1 CWD931018
←
29 TEMPERATURE SENSOR 1 CWA50C608
←
0
30 CONTROL BOARD FRONT COVER 1 CWH13456
←
31 CONTROL BOARD TOP COVER 1 CWH13457
←
32 REMOTE CONTROL COMPLETE 1 CWA75C2079
←
0
33 FRONT GRILLE COMPLETE 1 CWE11C2106
←
34 INTAKE GRILLE COMPLETE 1 CWE22C1006
←
35 DECORATION BASE COMPLETE 1 CWE35C1007
←
36 TAB 2 CWD931020
←
37 AIR FILTER 2 CWD00240
←
38 GRILLE DOOR 1 CWE141013
←
39 SCREW FOR FRONT GRILLE 2 XTN4+16C
←
40 CAP FOR FRONT GRILLE 2 CWH52267
←
41 DRAIN HOSE 1 CWH5880580
←
42 INSTALLATION PLATE 1 CWH36157
←
43 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1067
←
44 AIR PURIFYING FILTER COMPLETE 1 CWD00C1028
←
45 AIR PURIFYING FILTER (CATECHIN) 2 CWD001014
←
0
46 AIR PURIFYING FILTER (DEODORIZING) 2 CWD001033
←
0
47 REMOTE CONTROL HOLDER 1 CWH36161
←
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
