(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CU-PC12KKF CU-PC18KKF REMARK
1 CHASSY ASS’Y 1 CWD50K2088
←
2 SOUND PROOF MATERIAL 1 CWG302110 -
3 FAN MOTOR BRACKET 1 CWD541030 CWD541030B
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ←
5 FAN MOTOR 1 CWA951676 ← O
6 SCREW - FAN MOTOR MOUNT 3 CWH55406J ←
7 PROPELLER FAN ASS’Y 1 CWH03K1006 ←
8 NUT - PROPELLER FAN 1 CWH56053J ←
9 COMPRESSOR 1 2KS210D5AA06 2KS324D5AA06 O
11 ANTI - VIBRATION BUSHING 3 CWH50055 ←
12 NUT - COMPRESSOR MOUNT 3 CWH561049 ←
13 CONDENSER 1 CWB32C2821 CWB32C2795
14 CAPILLARY TUBE ASS’Y 1 CWB15K1165 CWB15K1208
15 STRAINER 1 CWB111011 CWB11025
16 HOLDER COUPLING 1 CWH351023 CWH351046
17 2-WAY VALVE (LIQUID) 1 CWB021362 CWB021488
18 3-WAY VALVE (GAS) 1 CWB011482 ← O
21 TERMINAL COVER 1 CWH171012 ← O
22 NUT - TERMINAL COVER 1 CWH7080300J ←
23 SOUND PROOF BOARD 1 CWH151023 ←
24 TERMINAL BOARD ASS’Y 1 CWA28K1064J CWA28K1033J
25 CAPACITOR - COM. 1 F0GAH356A001 DS441456CPND O
26 HOLDER CAPACITOR 1 CWH30060 CWH30071 O
27 CAPACITOR - F.M 1 DS441205NPQA ←
28 CABINET SIDE PLATE 1 CWE041248A ← O
30 CABINET SIDE PLATE COMPLETE 1 CWE04C1118 CWE04C1120
31 CABINET FRONT PLATE ASS’Y 1 CWE06K1034 ←
32 CABINET TOP PLATE 1 CWE031014A ←
33 CONTROL BOARD COVER COMP 1 CWH13C1064 ←
34 WIRE NET 1 CWD041111A ←
35 THERMOSTAT 1 - CWA151060
36 V-COIL COMPLETE 1 - CWA43C2282
37 HANDLE 1 CWE161010 ←
38 2-WAYS VALVE 1 - CWB021394
