Thank you for purchasing Panasonic Air Conditioner.
Installation instructions attached.
Before operating the unit, please read these operating instructions thoroughly and keep them for future
reference.
The illustrations in this manual are for explanation purposes only and may differ from the actual unit.
They are subject to change without notice for future improvement.
Operation conditions
Use this air conditioner under the following temperature range.
DBT : Dry bulb temperature
WBT : Wet bulb temperature
Temperature (°F/°C)
Indoor Outdoor
DBT WBT DBT WBT
COOL
Max. 89.6/32 73.4/23 114.8/46 78.8/26
Min. 60.8/16 51.8/11 0/-17.8 -/-
HEAT
Max. 86.0/30 -/- 75.2/24 64.4/18
Min. 60.8/16 -/- -4/-20 -2.2/-19
Power Supply
Models Number Time Delay Circuit Breaker Rated Volts
CS-RE9SKUA / CU-RE9SKUA 15 Amps
208/230V
CS-RE12SKUA / CU-RE12SKUA 20 Amps
