7
2.2. CS-RE24GKE CU-RE24GKE
ITEM UNIT INDOOR UNIT OUTDOOR UNIT
Performance Test Condition EUROVENT
C
O
O
L
I
N
G
Capacity
kW 6.8 (0.90 ~ 8.10)
BTU/h 23200 (3070 ~ 27600)
*kCal/h 5850 (770 ~ 6970)
EER
W/W (Class) 3.21 (2.57 ~ 3.00)
BTU/hW 10.9 (8.8 ~ 10.2)
Noise Level
dB (A) High: 47, Low: 38 High: 52
Power level dB High: 60 High: 66
H
E
A
T
I
N
G
Capacity
kW 8.60 (0.90 ~ 9.90)
BTU/h 29300 (3070 ~ 33800)
*kCal/h 7400 (770 ~ 8510)
COP
W/W (Class) 3.23 (2.50 ~ 3.09)
BTU/hW 11.0 (8.5 ~ 10.6)
Noise Level
dB (A) High: 47, Low: 38 High: 52
Power level dB High: 60 High: 66
Moisture Removal
l/h 3.9
pt/h 8.2
Air Volume
Lo
Cooling
m
3
/min (ft
3
/min)
16.9 (600) —
Heating 18.3 (650) —
Hi
Cooling
m
3
/min (ft
3
/min)
16.9 (600) 54.5 (1925)
Heating 18.3 (650) 54.5 (1925)
Refrigeration Control Device — Expansion Valve
Refrigeration Oil (Charged)
cm
3
— FV50S (800)
Refrigerant (Charged) R410A kg (oz) — 1.65 (58.2)
Dimension
Height mm (inch) 275 (10-13/16) 795 (31-5/16)
Width mm (inch) 998 (39-9/32) 900 (35-7/16)
Depth mm (inch) 230 (9-1/16) 320 (12-19/32)
Net Weight kg (lbs) 11 (24) 67 (148)
Pipe Diameter
Gas mm (inch) 15.88 (5/8”)
Liquid mm (inch) 6.35 (1/4”)
Height Difference m (ft) 20.0 (65.6)
Pipe Length Range m (ft) 3 (9.8) ~ 30 (98.4)
Additional Gas Amount g/m (oz/ft) 30 (0.3)
Refrigeration Charge Less m (ft) 10.0 (32.8)
Drain Hose
Inner Diameter mm 16 —
Length mm 650 —
Compressor
Type — Scroll
Motor Type — Brushless (4-pole)
Rated Output W — 1.70k
Fan
Type Cross-Flow Fan Propeller Fan
Material ASHT-18 PP (MICA 30% + GF 10%)
Motor Type Transistor (8-poles) Induction (6-poles)
Input Power W 85.1 97.8
Output Power W 30 76
Fan Speed
Lo (Cool/Heat) rpm 1560 / 1680 —
Me (Cool/Heat) rpm — —
Hi (Cool/Heat) rpm 1560 / 1680 700
SHi (Cool/Heat) rpm — —
Heat Exchanger
Fin Material Aluminium (Pre coat) Aluminium
Fin Type Slit Fin Corrugated Fin
Row x Stage x FPI 2 x 15 x 21 2 x 30 x 19
Size (W x H x L) mm 810 x 315 x 25.4 38.1 x 762 x 873.8:903.8
