PRODUCT OVERVIEW & OPERATIONS PRODUCT OVERVIEW & OPERATIONS
Auto OFF/ON button
• Used when remote control is misplaced or
malfunction.
Step Action Mode
1 Press once. Auto
2
Press and hold until 1 beep
is heard, then release.
Force
Cooling
3
Press and hold until you
hear double beep sound,
then release.
Force
Heating
Press the button to turn off.
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote control
display to prevent the unit from starting / stopping improperly.
TO SET TEMPERATURE
• Selection range: 16˚C ~ 30˚C.
• Operating the unit within the recommended temperature could
induce energy saving.
HEAT mode : 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
TO SELECT OPERATION MODE
AUTO mode - For your convenience
• To set the temperature by pressing
or .
• During Automatic Operation, the operation mode will be selected
automatically in accordance with the room temperature, outdoor
air temperature and set temperature of remote control.
• The operation mode changes every half hour if necessary.
36
32
25
18
16
13 19 21 23 25
HEAT DRY COOL
Room Temperature
(Example) Setting Temp at 25
Outdoor Temperature
22
HEAT mode - To enjoy warm air
• Unit takes a while to warm up.
COOL mode - To enjoy cool air
DRY mode - To dehumidify the environment
• Unit operates at low fan speed to give a gentle cooling operation.
Maximum distances: 8m
Remote
control
display
WARNING
• Be careful not to
insert your fi ngers
into the unit to
avoid injuring by
cross-fl ow fan.
INDICATOR
(GREEN)
(ORANGE)
(GREEN)
(RED)
F566894_EN1.indd 章节2:4F566894_EN1.indd 章节2:4 2009-6-15 10:32:132009-6-15 10:32:13
