< Model : CS-S18HKH CS-S24HKH >
(NOTE)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF NO. PART NAME & DESCRIPTION QTY. CS-S18HKH CS-S24HKH REMARKS
1 CHASSY COMPLETE 1 CWD50C1520 m
2 FAN MOTOR 1 ARW61G8P30AC m O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010 m
4 SCREW - CROSS FLOW FAN 1 CWH551146 m
5 BEARING ASS’Y 1 CWH64K007 m
6 EVAPORATOR 1 CWB30C2260 CWB30C2259
7 FLARE NUT 1 CWT251030 (1/4”) m
8 FLARE NUT 1 CWT251032 (1/2”) CWT251033 (5/8”)
9 HOLDER SENSOR 1 CWH32143 m
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2753 m
11 VERTICAL VANE 15 CWE241088 m
12 CONNECTING BAR 1 CWE261025 m
13 AIR SWING MOTOR 1 CWA98260+MJ m O
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849 m
14 AIR SWING MOTOR 1 CWA98K1009 m O
16 HORIZONTAL VANE 1 CWE241228A m
17 HORIZONTAL VANE 1 CWE241229A m
18 CAP - DRAIN TRAY 1 CWH521096 m
19 BACK COVER CHASSIS 1 CWD932162B m
20 CONTROL BOARD CASING 1 CWH102334 m
21 TERMINAL BOARD COMPLETE 1 CWA28C2305 m O
22 P.S. CORD 1 CWA20C2617 CWA20C2663
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C3028 CWA73C3032 O
24 INDICATOR COMPLETE 1 CWE39C1179 m O
25 INDICATOR HOLDER 1 CWD932871 m
26 INDICATOR HOLDER 1 CWD932872 m
27 SENSOR COMPLETE 1 CWA50C2122 m O
28 CONTROL BOARD TOP COVER 1 CWH131209 m
29 CONTROL BOARD FRONT COVER 1 CWH131210 m
30 REMOTE CONTROL COMPLETE 1 CWA75C3153 m O
31 FRONT GRILLE COMPLETE 1 CWE11C3872 m O
32 INTAKE GRILLE COMPLETE 1 CWE22C1405 m O
33 GRILLE DOOR 1 CWE141076 m
34 E-ION FILTER 2 CWD00K1005 m
36 SCREW - FRONT GRILLE 3 XTT4+16CFJ m
37 CAP - FRONT GRILLE 3 CWH521062A m
38 DRAIN HOSE 1 CWH851063 m
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067 m
40 INSTALLATION PLATE 1 CWH36K1007 m
41 FULCRUM 2 CWH621073 m
42 E-ION AIR PURIFYING SYSTEM 1 CWH14C5600 m
43 ION-GENERATOR 1 CWH94C0014 m
51 ELECTRONIC CONTROLLER - POWER 1 CWA745112 m O
To Next Page
