< Model : CU-S24HKH >
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SFSC0711-00
REF. NO. DESCRIPTION & NAME QTY. CU-S24HKH REMARKS
1 CHASSY ASS’Y 1 CWD50K2085
2 ANTI-VIBRATION BUSHING 3 CWH50077
3 COMPRESSOR 1 5CS130XAD04 O
4 NUT-COMPRESSOR MOUNT 3 CWH56000J
5 SOUND PROOF MATERIAL 1 CWG302302
6 FAN MOTOR BRACKET 1 CWD541065
7 FAN MOTOR 1 CWA951599 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551217
9 SCREW - FAN MOTOR MOUNT 3 CWH555252J
10 PROPELLER FAN ASSY 1 CWH03K1017
11 NUT - PROPELLER FAN 1 CWH56053J
12 CONDENSER 1 CWB32C2247
15 TUBE ASS’Y (CAP. TUBE) 1 CWB15K1232 O
16 STRAINER 1 CWB11025
18 HOLDER - COUPLING 1 CWH351057
19 3 WAYS VALVE (GAS) 1 CWB011362 O
20 2 WAYS VALVE (LIQUID) 1 CWB021419 O
22 SOUND PROOF BOARD 1 CWH151050
23 TERMINAL COVER 1 CWH171039A
24 NUT-TERMINAL COVER 1 CWH7080300J
26 HOLDER SENSOR 1 CWMH320001
27 HOLDER SENSOR 1 CWH32074
29 SENSOR COMPLETE (COMP. DISC.) 1 CWA50C2185
30 SENSOR COMPLETE 1 CWA50C2181
31 REACTOR 1 G0C153J0005
32 CONTROL BOARD CASING (SIDE) 1 CWH102273
33 TERMINAL BOARD ASSY 1 CWA28K1036J
34 FUSE HOLDERS 1 K3GB1PH00016
35 FUSE 1 K5D303BBA002
36 CONTROL BOARD COVER (TOP) 1 CWH131167
37 CONTROL BOARD CASING (BOTTOM) 1 CWH102282
38 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2966R O
41 CABINET SIDE PLATE (LEFT) 1 CWE041207A
42 HANDLE 1 CWE161010
43 CABINET SIDE PLATE (RIGHT) 1 CWE041208A
44 HANDLE 2 CWE16000E
45 CABINET FRONT PLATE CO. 1 CWE06K1043
47 CABINET TOP PLATE 1 CWE031031A
48 CONTROL BOARD COVER (BOTTOM) 1 CWH131168
49 CONTROL BOARD COVER (TOP) 1 CWH131169A
50 OPERATING INSTRUCTION 1 CWF565832
52 INSTALLATION INSTRUCTION 1 CWF613341
