REF NO. PART NAME & DESCRIPTION QTY. CS-S18MKQ CS-S24MKQ CS-S28MKQ REMARK
1 CHASSY COMPLETE 1 CWD50C1623 ← ←
2 FAN MOTOR 1 ARW7628AC ARW7627AC ← O
3 CROSS FLOW FAN COMPLETE 1 CWH02C1077 ← ←
4 BEARING ASS’Y 1 CWH64K007 ← ←
5 SCREW - CROSS FLOW FAN 1 CWH551146 ← ←
6 ION GENERATOR 1 CWH94C0028 ← ←
7 EVAPORATOR 1 CWB30C2584 CWB30C2775 CWB30C2776
8 FLARE NUT (LIQUID) 1 CWT251030 ← ←
9 FLARE NUT (GAS) 1 CWT251032 CWT251033 ←
10 E-ION AIR PURIFYING SYSTEM 1 CWD93C1090 ← ←
11 HOLDER SENSOR 1 CWH32143 ← ←
12 CONTROL BOARD CASING 1 CWH102370 ← ←
13 TERMINAL BOARD COMPLETE 1 CWA28C2357 ← ← O
14 ELECTRONIC CONTROLLER - MAIN 1 CWA73C5311 CWA73C5312 CWA73C5313 O
15 ELECTRONIC CONTROLLER - POWER 1 CWA746252 ← CWA746253 O
16 ELECTRONIC CONTROLLER - HVU 1 CWA745348 ← ← O
17 ELECTRONIC CONTROLLER - INDICATOR 1 CWA746280 ← ← O
18 ELECTRONIC CONTROLLER - RECEIVER 1 CWA745288 ← ← O
19 SENSOR COMPLETE 1 CWA50C2401 ← ← O
20 CONTROL BOARD TOP COVER 1 CWH131350 ← ←
21 INDICATOR HOLDER 1 CWD933021 ← ←
22 CONTROL BOARD FRONT COVER 1 CWH13C1183 ← ←
23 DISCHARGE GRILLE COMPLETE 1 CWE20C3124 ← ←
24 FULCRUM 2 CWH621103 ← ←
25 VERTICAL VANE 15 CWE241355 ← ←
26 CONNECTING BAR 1 CWE261220 ← ←
27 CONNECTING BAR 1 CWE261158 ← ←
28 CONNECTING BAR 1 CWE261221 ← ←
29 CONNECTING BAR 1 CWE261159 ← ←
30 CONNECTING BAR 1 CWE261160 ← ←
31 A.S.MOTOR, DC SINGLE 12V 300OHM 1 CWA981241 ← ← O
32 A.S MOTOR, DC SINGLE 12V 300OHM 1 CWA98K1015 ← ← O
34 CAP - DRAIN TRAY 1 CWH521096 ← ←
35 HORIZONTAL VANE 1 CWE24C1364 ← ←
36 BACK COVER CHASSIS 1 CWD933031 ← ←
37 REMOTE CONTROL CO. (WIRELESS) 1 CWA75C3702 ← ← O
38 FRONT GRILLE COMPLETE 1 CWE11C4786 ← CWE11C4787 O
39 INTAKE GRILLE COMPLETE 1 CWE22C1679 ← ←
40 GRILLE DOOR 1 CWE14C1029 ← ←
41 E-ION FILTER 2 CWD00K1017 ← ←
42 SCREW - FRONT GRILLE 4 XTT4+16CFJ ← ←
43 CAP - FRONT GRILLE 3 CWH521194 ← ←
44 DRAIN HOSE 1 CWH851174 ← ←
45 INSTALLATION PLATE 1 CWH361098 ← ←
46 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1705 ← ←
47 OPERATING INSTRUCTION 1 CWF567960 ← ←
48 INSTALLATION INSTRUCTION 1 CWF614750 ← CWF614752
49 INSTALLATION INSTRUCTION 1 CWF614751 ← CWF614753
51 ELECTRONIC CONTROLLER (COMPARATOR) 1 CWA746205 ← ← O
52
ELECTRONIC CONTROLLER (ECO SENSOR -
L)
1 CWA745791 ← ← O
53
ELECTRONIC CONTROLLER (ECO SENSOR -
R)
1 CWA746206 ← ← O
54 SENSOR COMPLETE (ECO) 1 CWA50C2759 ← ← O
55 LEAD WIRE - PCB ECO 1 CWA67C9218 ← ←
56 CONTROL BOARD CASING FOR PCB ECO 1 CWD93C1108 ← ←
