4.2 Outdoor Unit
4.2.1 CU-S9MKQ
4.2.2 CU-S12MKQ
Space necessary for
installation
Anchor Bolt Pitch
261 x 474
<Top View>
<Front View>
18
(650)
88 474 88
79
134
261
293
736
(18)
70
131
510
12 15
230
<Side View>
<Side View>
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
10 cm
Unit: mm
10 cm
100 cm
