Panasonic CS-S18MKQ Service Manual

9
Indoor CS-S28MKQ
Model
Outdoor CU-S28MKQ
Performance Test Condition JIS
Phase, Hz Single, 60
Power Supply
V 220 230
Min. Mid. Max. Min. Mid. Max.
kW 1.15 7.80 8.40 1.15 7.80 8.40
BTU/h 3920 26600 28600 3920 26600 28600
Capacity
kJ/h 4140 28080 30240 4140 28080 30240
Running Current A - 12.6 - - 12.2 -
Input Power W 350 2.70k 2.95k 350 2.70k 2.95k
W/W 3.29 2.89 2.85 3.29 2.89 2.85
BTU/hW 11.20 9.85 9.69 11.20 9.85 9.69
EER
kJ/hW 11.83 10.40 10.25 11.83 10.40 10.25
Power Factor % - 97 - - 96 -
dB-A 49 / 38 / 35 49 / 38 / 35
Indoor Noise (H / L / QLo)
Power Level dB - -
dB-A 53 / - / - 53 / - / -
Cooling
Outdoor Noise (H / L)
Power Level dB - -
Max Current (A) / Max Input Power (W) 14.6 / 3.26k
Starting Current (A) 12.6
Type Hermetic Motor
Motor Type Brushless (4 poles)
Compressor
Output Power W 1.70k
Type Cross-Flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W 94.8
Output Power W 40
QLo rpm 950
Lo rpm 1050
Me rpm 1300
Hi rpm 1540
Indoor Fan
Speed
SHi rpm 1600
Type Propeller Fan
Material PP Resin
Motor Type Induction (6-poles)
Input Power W -
Output Power W 62
Me rpm -
Outdoor Fan
Speed
Hi rpm 660 - 680
Moisture Removal L/h (Pt/h) 4.6 (9.7)
QLo m
3
/min (ft
3
/min) 10.9 (385)
Lo m
3
/min (ft
3
/min) 12.5 (441)
Me m
3
/min (ft
3
/min) 16.3 (576)
Hi m
3
/min (ft
3
/min) 20.4 (720)
Indoor Airflow
SHi m
3
/min (ft
3
/min) 21.4 (756)
Outdoor Airflow Hi m
3
/min (ft
3
/min) 51.8 (1830) 53.5 (1890)

Panasonic CS-S18MKQ Specifications

General

Brand	Panasonic
Model	CS-S18MKQ
Category	Air Conditioner
Language	English
