29
2. When Powerful operation is stopped, operation is shifted to normal operation.
C. Control Contents
a. Fan speed
1.Indoor fan speed depends on indoor intake temperature and remote control setting temperature. Fan speed is changed
from normal setting to Powerful setting of respective fan speed.
b. Temperature shifting
1.Internal setting temperature shift depends on indoor pipe temperature. Temperature is decreased (Cooling and Soft Dry
operation) or increased (Heating operation) accordingly.
12.5. ON Timer Control
ON timer can be set using remote control, the unit with timer set will start operate earlier than the setting time. This is to provide a
comfortable environment when reaching the set ON time.
70 minutes before the set time, indoor (at fan speed of Lo-) and outdoor fan motor start operate for 30 seconds to determine the
indoor intake air temperature and outdoor air temperature in order to judge the operation starting time.
From the judgment, the decided operation will start operate earlier than the set time as shown below.
12.6. OFF Timer Control
OFF timer can be set using remote control, the unit with timer set will stop operate at set time.
12.7. Auto Restart Control
1. When the power supply is cut off during the operation of air conditioner, the compressor will re-operate within three to four
minutes (there are 10 patterns between 2 minutes 58 seconds and 3 minutes 52 seconds to be selected randomly) after
power supply resumes.
2. This type of control is not applicable during ON/OFF Timer setting.
12.8. Indication Panel
Note:
• If POWER LED is blinking, the possible operations of the unit are Hot Start, during Deice operation, operation mode judgement,
or ON timer sampling.
• If Timer LED is blinking, there is an abnormality operation occurs.
LED POWER TIMER Ion
Color Green Orange Blue
Light ON Operation ON Quiet Setting ON Ion ON
Light OFF Operation OFF Quiet Setting OFF Ion OFF
