12
Indoor
Model CS-Z20TKR CS-Z25TKR
POS (EAN) 5025232871452 5025232871469
Outdoor
Model CU-Z20TKR CU-Z25TKR
POS (EAN) 5025232871643 5025232871650
Dimension
Unit
Height
(I/D / O/D)
mm (inch) 295 (11-5/8) / 542 (21-11/32) 295 (11-5/8) / 542 (21-11/32)
Width
(I/D / O/D)
mm (inch) 919 (36-3/16) / 780 (30-23/32) 919 (36-3/16) / 780 (30-23/32)
Depth
(I/D / O/D)
mm (inch) 194 (7-21/32) / 289 (11-13/32) 194 (7-21/32) / 289 (11-13/32)
PCKG.
(Stacking
Condition)
Height
(I/D / O/D)
mm (inch) 234 (9-7/32) / 603 (23-3/4) 234 (9-7/32) / 603 (23-3/4)
Width
(I/D / O/D)
mm (inch) 960 (37-13/16) / 891 (35-3/32) 960 (37-13/16) / 891 (35-3/32)
Depth
(I/D / O/D)
mm (inch) 360 (14-3/16) / 396 (15-19/32) 360 (14-3/16) / 396 (15-19/32)
Weight
Net (I/D / O/D) kg (lb) 9 (20) / 32 (71) 10 (22) / 32 (71)
Gross (I/D / O/D) kg (lb) 10 (22) / 34 (75) 11 (24) / 34 (75)
Stacking No. (CS / CU / CZ) Actual Stacking Quantity (12 / 6 / -) Actual Stacking Quantity (12 / 6 / -)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard Length m (ft) 5.0 (16.4) 5.0 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 20 (65.6) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 10 (0.1)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 15 x 21 2 x 15 x 21
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium (Blue Coat) Aluminium (Blue Coat)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x FPI 2 x 24 x 19 2 x 24 x 19
Size (W x H x L) mm 36.4 x 504 x 824.2:793.7 36.4 x 504 x 824.2:793.7
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Outdoor Power Supply Outdoor Power Supply
Power Supply Cord A Nil Nil
Thermostat Electronic Contol Electronic Contol
Protection Device Electronic Contol Electronic Contol
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation Range
Cooling
Maximum °C 32 23 32 23
Minimum °C 16 11 16 11
Heating
Maximum °C 30 - 30 -
Minimum °C 16 - 16 -
Outdoor Operation Range
Cooling
Maximum °C 46 26 46 26
Minimum °C 5 - 5 -
Heating
Maximum °C 24 18 24 18
Minimum °C -15 - -15 -
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb
(44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Heating low temperature capacity, Input Power and COP measured at 230V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230V, indoor temperature 20°C, outdoor -7/-8°C.
5. Specifications are subjected to change without prior notice for further improvement.
