Panasonic CS-Z20TKR User Manual

26
6.2 Outdoor Unit
6.2.1 CU-Z20TKR CU-Z25TKR CU-Z35TKR
18
69.5 61.6
542
28939
570
22
104.7
67.6
780
85.5
155.2
34.3
60.5
104.9
Space necessary for
installation
Anchor Bolt Pitch
320 x 570
100 cm
10 cm
10 cm
<Side View>
<Side View>
<Front View>
<Chassis>
<Top View>
Unit: mm
2-way valve at
Liquid side
(High Pressure)
3-way valve at
Gas side
(Low Pressure)
777.6
287.2
Ø20
320
6.2.2 CU-Z42TKR CU-Z50TKR CU-Z60TKR CU-Z71TKR
(25)
7570.5
695
320
386
45
7.7
61334.7
(131)
72875
3582
360.5
131
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Anchor Bolt Pitch
360.5 × 613
Space necessary for
installation
100 mm
100 mm
1000 mm
<Chassis>
872.6
318.2
Ø20
