152
18.1.1.8 To Assemble the Intake Grille
Hook
Inta
k
eGrille
22.
Align the intake grille
hooks into the slot.
Hook
23.
Place in the hook to the slot.
24.
Then slightly bend the intake grille
and push in the hooks into the slot.
Figure 14
