Panasonic CS-Z20TKR

21
Indoor
Model CS-Z71TKR CS-Z80TKR
POS (EAN) 5025232871513 5025232871520
Outdoor
Model CU-Z71TKR CU-Z80TKR
POS (EAN) 5025232871704 5025232871711
Dimension
Unit
Height
(I/D / O/D)
mm (inch) 302 (11-29/32) / 695 (27-3/8) 302 (11-29/32) / 795 (31-5/16)
Width
(I/D / O/D)
mm (inch) 1120 (44-1/8) / 875 (34-15/32) 1120 (44-1/8) / 875 (34-15/32)
Depth
(I/D / O/D)
mm (inch) 236 (9-5/16) / 320 (12-5/8) 236 (9-5/16) / 320 (12-5/8)
PCKG.
(Stacking
Condition)
Height
(I/D / O/D)
mm (inch) 282 (11-1/8) / 796 (31-11/32) 282 (11-1/8) / 894 (35-7/32)
Width
(I/D / O/D)
mm (inch) 1190 (46-7/8) / 1049 (41-5/16) 1190 (46-7/8) / 1049 (41-5/16)
Depth
(I/D / O/D)
mm (inch) 378 (14-29/32) / 460 (18-1/8) 378 (14-29/32) / 485 (19-1/8)
Weight
Net (I/D / O/D) kg (lb) 13 (29) / 50 (110) 13 (29) / 60 (132)
Gross (I/D / O/D) kg (lb) 15 (33) / 54 (119) 15 (33) / 66 (146)
Stacking No. (CS / CU / CZ) Actual Stacking Condition (12 / 4 / -) Actual Stacking Condition (12 / 4 / -)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 15.88 (5/8) 6.35 (1/4) / 15.88 (5/8)
Standard Length m (ft) 5.0 (16.4) 5.0 (16.4)
Length Range (min – max) m (ft) 3 (9.8) ~ 30 (98.4) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height Different m (ft) 20 (65.6) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 25 (0.3) 25 (0.3)
Length for Additional Gas m (ft) 10 (32.8) 10 (32.8)
Drain Hose
Inner Diameter mm 16.7 16.7
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 17 x 21 2 x 17 x 21
Size (W x H x L) mm 836.5 x 357 x 25.4 836.5 x 357 x 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium (Blue Coat) Aluminium (Blue Coat)
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x FPI 2 x 31 x 19 2 x 30 x 19
Size (W x H x L) mm 36.4 x 651 x 904.5:874.5 38.1 x 762 x 895.8:865.8
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Outdoor Power Supply Outdoor Power Supply
Power Supply Cord A Nil Nil
Thermostat Electronic Contol Electronic Contol
Protection Device Electronic Contol Electronic Contol
Dry Bulb Wet Bulb Dry Bulb Wet Bulb
Indoor Operation Range
Cooling
Maximum °C 32 23 32 23
Minimum °C 16 11 16 11
Heating
Maximum °C 30 - 30 -
Minimum °C 16 - 16 -
Outdoor Operation Range
Cooling
Maximum °C 46 26 46 26
Minimum °C 5 - 5 -
Heating
Maximum °C 24 18 24 18
Minimum °C -15 - -15 -
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor air temperature of 7°C Dry Bulb
(44.6°F Dry Bulb), 6°C Wet Bulb (42.8°F Wet Bulb).
3. Heating low temperature capacity, Input Power and COP measured at 230V, indoor temperature 20°C, outdoor 2/1°C.
4. Heating extreme low temperature capacity, Input Power and COP measured at 230V, indoor temperature 20°C, outdoor -7/-8°C.
5. Specifications are subjected to change without prior notice for further improvement.
