14
Indoor
Model CS-Z35UD3RAW
POS (EAN) 5025232886920
Outdoor
Model CU-Z35UBRA
POS (EAN) 5025232885473
Performance Test Condition AS
Power Supply
Phase, Hz Single, 50
V 230 240
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.85 3.70 4.00 0.85 3.70 4.00
BTU/h 2900 12600 13600 2900 12600 13600
kcal/h 730 3180 3440 730 3180 3440
Running Current A – 4.30 – – 4.20 –
Input Power W 240 960 1.12k 240 960 1.12k
EER / EER CLASS W/W 3.54 3.85 / 3.0 3.57 3.54 3.85 / 3.0 3.57
EER
BTU/hW 12.08 13.13 12.14 12.08 13.13 12.14
kcal/hW 3.04 3.31 3.07 3.04 3.31 3.07
Power Factor % – 97 – – 95 –
Indoor Noise (H / L / QLo)
dB-A 33 / 26 / 23
Power Level dB 49 / 42 / 39
Outdoor Noise (H / L / QLo)
dB-A 49 / – / –
Power Level dB 64 / – / –
Heating
Capacity
kW 0.85 4.20 5.60 0.85 4.20 5.60
BTU/h 2900 14300 19100 2900 14300 19100
kcal/h 730 3610 4820 730 3610 4820
Running Current A – 4.70 – – 4.50 –
Input Power W 230 1.03k 1.57k 230 1.03k 1.57k
COP / COP CLASS W/W 3.70 4.08 / 3.5 3.57 3.70 4.08 / 3.5 3.57
COP
BTU/hW 12.61 13.88 12.17 12.61 13.88 12.17
kcal/hW 3.17 3.50 3.07 3.17 3.50 3.07
Power Factor % – 95 – – 95 –
Indoor Noise (H / L / QLo)
dB-A 35 / 27 / 24
Power Level dB 51 / 43 / 40
Outdoor Noise (H / L / QLo)
dB-A 50 / – / –
Power Level dB 65 / – / –
H2
Capacity kW 3.70
Input Power kW 1.20
COP W/W 3.08
Powerful
Heat
Capacity kW 5.60
Input Power kW 1.57
COP W/W 3.57
Max Current (A) / Max Input Power (W) 6.6 / 1.42k
Starting Current (A) 4.70
Compressor
Type Hermetic Motor (Rotary)
Motor Type Brushless (6 poles)
Output Power W 700
