32
7.2 CS-Z50UD3RAW CU-Z50UBRA CS-Z60UD3RAW CU-Z60UBRA
INDOOR OUTDOOR
INTAKE
AIR
TEMP.
SENSOR
PIPE
TEMP.
SENSOR
AIR
TEMP.
SENSOR
LIQUID
SIDE
2-WAY
VALVE
3-WAY
VALVE
GAS
SIDE
COOLING
HEAT EXCHANGER
(EVAPORATOR)
HEATING
COMPRESSOR
CONDENSER
PROCESS
TUBE
STRAINER
EXPANSION
VALVE
4-WAYS VALVE
TANK
SENSOR
PIPE
TEMP.
SENSOR 1
PIPE
TEMP.
SENSOR 2
RECEIVER
