6.2 Outdoor Unit
6.2.1 CU-Z25UBRA
(18)
69.5 61.6
542
28939
570.3
22
(104.7)
67.6
780
85.5
155.2 34.3
60.5104.9
Space necessary for
installation
Anchor Bolt Pitch
320
× 570
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
1000 mm
100 mm
100 mm
<Chassis>
777.6
287.2
Ø2
0
