6.2.2 CU-Z35UBRA
<Top View>
<Front View><Side View>
<Side View>
Anchor Bolt Pitch
330 × 540
Space necessary for
installation
100 mm
100 mm
1000 mm
Unit : mm
3-way valve at Gas side
(Low Pressure)
2-way valve at Liquid side
(High Pressure)
22 (124) (62.6)
330
619
167
97
69
(20)
62
32
540 160
824 68.7
37 299
<Chassis>
822
297
Ø20
