154
21.3.2 CS-Z35UD3RAW CU-Z35UBRA
Cooling Capacity Correction Factor
Pipe Length (m)
0.90
1.00
1.10
2 3 45678 910111213 14 15 16 17 18 19 20 21
Cooling Capacity
3 1.0080
5 1.0000
10 0.9850
20 0.9656
Heating Capacity Correction Factor
Pipe Length (m)
0.80
0.90
1.00
1.10
2 3 45678 910111213 14 15 16 17 18 19 20 21
Heating Capacity
3 1.0118
5 1.0000
10 0.9800
20 0.9392
Note: The graphs show the factor after added right amount of additional refrigerant.
